Squier Classic Vibe 50's Tele
Loc # Description
1
Neck (maple)
1a
Vintage Fret Wire (24)
2
Vintage Tuners (set of 6)
3
Bone Nut (blank)
4
String Guide
5
Body
6
Strap Buttons (2)
7
50's Tele Neck Pickup (import)
8
50's J Tele Bridge Pickup (import) 007-4935-000
9
Pickguard
9a
Pickguard Screws (24)
10
Control Plate
11-12 250K Pot (w/ mtg. hardware)
13
Chrome Knobs (ea)
14
3 Way Switch
15
Switch Tip (black)
16
Output Jack
17
Jack Plate
18
Bridge Assembly
18a
Bridge mounting screws (ea)
19
String Ferrules (ea)
20
Truss Rod Wrench
Maple-
m/n 0303025xxx
Part Number
N/A
099-2014-000
007-4936-000
099-4920-000
099-4912-000
N/A
099-4915-000
007-4934-000
007-7345-000
099-4923-000
007-4914-000
007-7348-000
007-4921-000
007-4910-000
007-4922-000
004-7329-049
007-7341-000
007-4944-000
007-7337-000
007-7334-000
007-4911-000
Last Revised: 9/12/2008
Page 1 of 3
