安裝 配件與規格 附註 •外部特徵與技術參數可能變更,以改善電器品質,恕不另⾏通知。 l 電源線 前視圖 m 冷水進水⼝ * 部分型號提供此功能。 附件 ( 視乎型號而定 ) *1 隨附的附件可能因購買的型號而異 *2 此配件不包含在產品中,您可從 LG 電⼦ 客戶服務中⼼購買。 a 冷水進水⼝軟管 b 排水軟管 c 索帶 a 機門 d 防鼠蓋 b 把手 e 防鼠蓋螺絲 c 鋼化玻璃 d 清潔劑分配器抽屜盒...
Page 8
Page 8 Wednesday, February 10, 2021 10:04 AM 安裝 規格 型號 WT-90WC 電源 220 V~, 50Hz 產品重量 約 30 kg 尺寸 (mm) D’ H’ 1155...
Page 36
Preparing Laundry ...................14 Adding Detergents, Softeners and Bleaches..........16 Control Panel ....................18 Programme Table ....................19 Extra Options and Functions ................21 SMART FUNCTIONS LG ThinQ Application ..................24 Smart Diagnosis ....................24 MAINTENANCE Cleaning after Every Wash................25 Cleaning the Appliance Periodically ..............25 TROUBLESHOOTING Before Calling for Service................29...
global_main.book.book Page 3 Wednesday, February 10, 2021 10:11 AM SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below.
Page 38
global_main.book.book Page 4 Wednesday, February 10, 2021 10:11 AM SAFETY INSTRUCTIONS • Children should be supervised to ensure that they do not play with the appliance. • Cleaning and user maintenance shall not be made by children without supervision. • If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
Page 39
global_main.book.book Page 5 Wednesday, February 10, 2021 10:11 AM SAFETY INSTRUCTIONS • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
Page 40
• Make sure that drainage is working properly. If water is not drained properly, your floor may get flooded. • If, during spinning, opening the door does not stop the drum within about 10 seconds, immediately discontinue operating the appliance and contact your dealer or LG Electronics service centre.
Page 41
• Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
Cold Water Inlet Accessories *1 The included accessories vary depending on the model you purchased. *2 This accessory is not included in the product, but you can purchase it from the LG service centre. Door Handle Cold Water Inlet Hose Tempered Glass...
Page 43
Page 9 Wednesday, February 10, 2021 10:11 AM INSTALLATION Model WT-90WC Product Weight Approx. 30 kg Dimension(mm) D’ H’ 1155...
Contact your local WARNING authorised LG repairer. • The power plug must be plugged into an • This appliance must only be used for domestic appropriate outlet socket that is installed and...
global_main.book.book Page 11 Wednesday, February 10, 2021 10:11 AM INSTALLATION Connecting the Water Inlet Connecting the Hose to the Water Tap Hoses Connecting Screw-Type Hose to Tap with Thread Before connecting the water inlet hose to the water Screw the hose connector onto the water supply tap, check the hose fitting type and then choose tap.
global_main.book.book Page 12 Wednesday, February 10, 2021 10:11 AM INSTALLATION Installing the Drain Hose Levelling the Appliance Before connecting the drain hose, check your drain Checking the Level hose model and choose the correct instruction. Levelling the appliance prevents unnecessary Installing the Drain Hose with noise and vibration.
Page 47
global_main.book.book Page 13 Wednesday, February 10, 2021 10:11 AM INSTALLATION Assembling the Anti-Rat Cover You can insert the anti-rat cover according to the type to protect the appliance from the rat. Flat Type Insert the flat type of the anti-rat cover to the assembling hole from the front of the appliance.
global_main.book.book Page 14 Wednesday, February 10, 2021 10:11 AM OPERATION OPERATION Operation Overview End of cycle. • When the cycle is finished, a melody will sound. Immediately remove your clothing Using the Appliance from the appliance to reduce wrinkling. Before the first wash, select the Normal programme and add a half amount of detergent.
Page 49
global_main.book.book Page 15 Wednesday, February 10, 2021 10:11 AM OPERATION Checking the Fabric Care Label cause irreparable damage to both your appliance and clothes. This will tell you about the fabric content of your clothes and how it should be washed. Symbols on the Care Labels Symbol Wash / Fabric type...
global_main.book.book Page 16 Wednesday, February 10, 2021 10:11 AM OPERATION Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring Detergent Dosage diluted liquid detergent into the drum might cause the clothes to be damaged, bleached, •...
Page 51
global_main.book.book Page 17 Wednesday, February 10, 2021 10:11 AM OPERATION Adding Fabric Softeners • Option washing is not designed to be used with fabric softener dispenser. • Dilute fabric softener with water. Undiluted fabric softener may result in spots that look like oil stain.
global_main.book.book Page 18 Wednesday, February 10, 2021 10:11 AM OPERATION Control Panel Control Panel Features POWER Button • Press this button to turn on or off the appliance. • The appliance automatically turns off once a certain time has passed after the wash has completed. START/PAUSE Button •...
global_main.book.book Page 19 Wednesday, February 10, 2021 10:11 AM OPERATION - The time shown is only an estimate. Several external factors (laundry size, room temperature, incoming water temperature, etc.) can affect the actual time. • : This icon turns on when the load sensing has detected the laundry size. •...
Page 54
global_main.book.book Page 20 Wednesday, February 10, 2021 10:11 AM OPERATION Duvet Description Use this programme to wash a blanket or bedclothes that have the hand wash sign on the care label. • Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket, infilling (polyester 101), and bed sheets might be damaged if they are allowed to float.
global_main.book.book Page 21 Wednesday, February 10, 2021 10:11 AM OPERATION Pre Wash+Normal Description Use this programme to pretreat immediate stain without handwash. • It is necessary for clothes which could smell bad if they are not washed promptly. Quick Wash Description Use this programme to wash lightly soiled clothes for a short time.
Page 56
global_main.book.book Page 22 Wednesday, February 10, 2021 10:11 AM OPERATION NOTE • If a rinse only cycle is selected, the water supply is started after detecting the load and this cycle will start. However this cycle will start to supply water of the selected water level if there is already water in the drum.
Page 57
global_main.book.book Page 23 Wednesday, February 10, 2021 10:11 AM OPERATION Manual Washing When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually. Rinse and Spin Spin only Rinse only Wash only Press the POWER button.
Page 24 Wednesday, February 10, 2021 10:11 AM SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided The LG ThinQ application allows you to in the LG ThinQ application.
global_main.book.book Page 25 Wednesday, February 10, 2021 10:11 AM MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. •...
Page 60
global_main.book.book Page 26 Wednesday, February 10, 2021 10:11 AM MAINTENANCE • Turn off the water taps to the appliance if the NOTE appliance is to be left for any length of time (e.g. holiday), especially if there is no floor drain •...
Page 61
global_main.book.book Page 27 Wednesday, February 10, 2021 10:11 AM MAINTENANCE your laundry items. Do not operate the Close the lid and then insert the lower part of appliance with the lint filters removed. the filter into the wash drum. Press the top of the filter until you hear a click sound.
Page 62
global_main.book.book Page 28 Wednesday, February 10, 2021 10:11 AM MAINTENANCE Remove any foreign objects and fluff inside pump casing and from the filter. Insert the filter along the guide ribs inside the pump casing and turn the cap clockwise to refit the cap.
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting.
Page 64
global_main.book.book Page 30 Wednesday, February 10, 2021 10:11 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Rebalancing operation is not successful. UNBALANCE ERROR • The automatic attempt to rebalance the laundry was not successful. The cycle has been paused to allow the laundry to be manually adjusted. The load is too small.
Page 65
global_main.book.book Page 31 Wednesday, February 10, 2021 10:11 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Vibrating noise Packaging materials are not removed. • Remove packing materials. The laundry may be unevenly distributed in the drum. • Pause the cycle and redistribute the laundry after the door unlocks. Not all levelling feet are resting firmly and evenly on the floor.
Page 66
global_main.book.book Page 32 Wednesday, February 10, 2021 10:11 AM TROUBLESHOOTING Operation Symptoms Possible Cause & Solution Appliance will not Control panel has powered off due to inactivity. operate. • This is normal. Press the POWER button to turn on the appliance. Appliance is unplugged.
Page 67
global_main.book.book Page 33 Wednesday, February 10, 2021 10:11 AM TROUBLESHOOTING Symptoms Possible Cause & Solution Water leaking Water inlet hose connection is loose at tap or appliance. • Check hoses for leaks, cracks and splits. • Tighten hose connections. House drain pipes are clogged. •...
Page 68
global_main.book.book Page 34 Wednesday, February 10, 2021 10:11 AM TROUBLESHOOTING Performance Symptoms Possible Cause & Solution Incomplete or no Too much detergent is used. dispensing of • Follow the guidelines provided by the detergent manufacturer. detergent Poor stain removal Previously set stains. •...
Page 69
global_main.book.book Page 35 Wednesday, February 10, 2021 10:11 AM Memo...
Page 70
global_main.book.book Page 35 Wednesday, February 10, 2021 10:11 AM Memo...
Page 71
global_main.book.book Page 35 Wednesday, February 10, 2021 10:11 AM Memo...
