OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
WT23WT6HA / WT23VT6HA
MFL68267095
Rev.01_110821
Copyright © 2021 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG WT23WT6HA
Summary of Contents for LG WT23WT6HA
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH WT23WT6HA / WT23VT6HA www.lg.com MFL68267095 Rev.01_110821 Copyright © 2021 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Preparing the Wash Load ................14 Adding Detergents, Softeners and Bleaches..........16 Control Panel ....................18 Programme Table ....................20 Extra Options and Functions ................22 SMART FUNCTIONS LG ThinQ Application ..................28 Smart Diagnosis ....................30 MAINTENANCE Cleaning after Every Wash ................31 Cleaning the Appliance Periodically ..............31 TROUBLESHOOTING... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 SAFETY INSTRUCTIONS • Children should be supervised to ensure that they do not play with the appliance. • Cleaning and user maintenance shall not be made by children without supervision. • If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
- Page 5 SAFETY INSTRUCTIONS • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.
- Page 6 • Make sure that drainage is working properly. If water is not drained properly, your floor may get flooded. • If, during spinning, opening the door does not stop the drum within about 10 seconds, immediately discontinue operating the appliance and contact your dealer or LG Electronics service centre.
- Page 7 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
-
Page 8: Installation Parts And Specifications
INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Rear View Door Hot and Cold Water Inlets Power Cord Control Panel Dispenser Drawer Drain Hose Bleach Dispenser *1 This feature is only available on some models. - Page 9 INSTALLATION *2 This accessory is not included in the product, but Cold and Hot Water Inlet Hoses you can purchase it from the LG service centre. Drain Hose Tie Strap Anti-Rat Cover Screw for Anti-Rat Cover Specifications Model WT23WT6HA / WT23VT6HA...
-
Page 10: Installation Place Requirements
Contact your local WARNING authorised LG repairer. • The power plug must be plugged into an • This appliance must only be used for domestic appropriate outlet socket that is installed and... -
Page 11: Connecting The Water Inlet Hoses
INSTALLATION Connecting the Water Inlet Connecting the Hose to the Water Tap Hoses Connecting Screw-Type Hose to Tap with Thread Before connecting the water inlet hose to the water Screw the hose connector onto the water supply tap, check the hose fitting type and follow the tap. -
Page 12: Installing The Drain Hose
INSTALLATION Installing the Drain Hose Adjusting and Levelling the Feet Before connecting the drain hose, check your drain hose model and follow the instructions for that When the appliance is not perfectly level, turn the model. adjustable feet until the appliance no longer wobbles. - Page 13 INSTALLATION CAUTION • Be careful your feet or hands when you lay or raise the appliance. Remove the sponge attached on the base. Insert the 8 screws into the holes to assemble the anti-rat cover to the appliance.
-
Page 14: Operation Operation Overview
OPERATION OPERATION Operation Overview End of cycle. • When the cycle is finished, a melody will sound. Immediately remove your clothing Using the Appliance from the appliance to reduce wrinkling. Before the first wash, select the Normal programme and add a half amount of detergent. Start the appliance without clothes. - Page 15 OPERATION Checking the Fabric Care Label cause irreparable damage to both your appliance and clothes. This will tell you about the fabric content of your clothes and how it should be washed. Symbols on the Care Labels Symbol Wash / Fabric type •...
-
Page 16: Adding Detergents, Softeners And Bleaches
OPERATION Adding Detergents, CAUTION Softeners and Bleaches • Using liquid detergent without diluting, or leaving laundry for a long time after pouring Detergent Dosage diluted liquid detergent into the drum might cause the clothes to be damaged, bleached, • Detergent should be selected according to fabric discoloured. - Page 17 OPERATION Adding Fabric Softeners bleach dispenser . Avoid splashing or overfilling. • Add a fabric softener to the maximum fill line. • If the softener is concentrated, then it should be diluted. • Mix powdered bleach with water to a liquid consistency and pour it into the bleach •...
-
Page 18: Control Panel
• You can use the extra options and functions to customize the programmes. Remote Start (Início Remoto) With the LG ThinQ app, you can use a smartphone to control your appliance remotely. • In order to use this function, refer to SMART FUNCTIONS. - Page 19 OPERATION Display • The display shows the settings, remaining estimated time, options, and status messages. When the appliance is turned on, the default settings in the display will light up. • : When a programme is selected, the default time for that programme is displayed. The time 18:88 can change as options are selected.
-
Page 20: Programme Table
OPERATION Programme Table Washing Programme Wash programmes are designed for the best wash performance for different types of clothes. • Turn the programme knob to select the desired programme. • When you select a wash programme, the light for the corresponding wash programme will turn on. Normal (Algodón/Normal) Description Use this programme to wash normal clothes. - Page 21 OPERATION Pre Wash+Normal (Prelavado+Normal) Description Use this programme to pretreat immediate stain without handwash. • It is necessary for clothes which could smell bad if they are not washed promptly. Delicates (Delicada) Description Use this programme to wash delicate fabrics such as lingerie and woolens. Before washing, check the care label for the washing instructions.
-
Page 22: Extra Options And Functions
OPERATION Duvet (Edredón) Description Use this programme to wash a blanket or bedclothes that have the hand wash sign on the care label. • This programme's recommended clothes amount is under 5 kg. • Cashmere bedclothes, acrylic blanket, mixed spinning blanket, woollen blanket, infilling (polyester 101), and bed sheets might be damaged if they are allowed to float. - Page 23 OPERATION Using Special Options Temp. (Temp. Lavado) This button selects the wash temperature for the Using Special Care Features selected programme. Press the Special Care (Cuidado Especial) button Press the Temp. (Temp. Lavado) button until the to select additional features, such as Soak desired setting is lit.
- Page 24 OPERATION • The washing machine can be turned on or NOTE restarted any time before the drain begins. However, once the washing machine begins to • Use very little detergent in this programme. To drain, all controls and functions will be disabled add an extra rinse, use the Extra Rinse until the water has been completely drained and (Enjuague Extra) button.
- Page 25 OPERATION • Selecting the Extra Rinse (Enjuague Extra) • Wash time will increase up to several minutes option with the Normal programme with this option. automatically changes the programme to the • Selecting this option increases the water Deep Wash (Lavado profundo) programme. supplied during rinsing.
- Page 26 OPERATION Signal (Señal) The washing machine plays a melody when the washing programme is finished. The buttons make a sound each time they are pressed. • Press the Signal (Señal) button to turn the sounds on or off. • When no signal is heard, the signal is off. The Signal (Señal) can be turned on at any time as long as the washing machine is turned on.
- Page 27 OPERATION Manual Washing When you need a rinse and spin, spin only, rinse only or wash only cycle, these can be set manually. Rinse (Enjuague) Wash (Lavado) Rinse (Enjuague) Spin (Centrifugado) only and Spin and Rinse Only (Centrifugado) (Enjuague) Press the POWER (ENCENDIDO/APAGADO) button. Select Rinse+Spin Select Rinse+Spin (Enjuague+...
-
Page 28: Smart Functions
SMART FUNCTIONS SMART FUNCTIONS LG ThinQ Application notifications on a smartphone. The notifications are triggered even if the LG ThinQ application is off. The LG ThinQ application allows you to communicate with the appliance using a smartphone. NOTE LG ThinQ Application Features •... - Page 29 To start the washing programme remotely in the wireless router manual. LG ThinQ application, set the Remote Start • LG ThinQ is not responsible for any network (Início Remoto) function. You can also monitor connection problems or any faults, your cycle operation so you know how much time malfunctions, or errors caused by network is left in the cycle.
-
Page 30: Smart Diagnosis
SMART FUNCTIONS (1) this equipment or device may not cause harmful • Launch the LG ThinQ application and select the interference and Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ (2) This equipment or device must accept any application. -
Page 31: Maintenance
MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish. - Page 32 MAINTENANCE Cleaning the Water Inlet Filter NOTE Water inlet filter collects lime or any small objects • For models without a lint filter, the lint is that may be in water supplied to the appliance. discharged when the water drains during Clean the water inlet filter regularly.
-
Page 33: Troubleshooting
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting. - Page 34 TROUBLESHOOTING Symptoms Possible Cause & Solution Foreign objects, such as coins, pins, clips, etc.,are caught between the pulsator and the inner drum. FOREIGN OBJECTS • Turn off the appliance and then press the POWER (ENCENDIDO/ ERROR • APAGADO) button. Press the Spin (Centrifugado) button without selecting a cycle to drain and spin the laundry.
- Page 35 TROUBLESHOOTING Symptoms Possible Cause & Solution Sensor for clothes-sensing is defective. CLOTHES SENSING • Manually redistribute the laundry if laundry have become tangled. ERROR Motor’s revolution is too low. Contact-point of Connector is defective. • Unplug the appliance and wait 60 seconds. Reconnect power and try again.
- Page 36 TROUBLESHOOTING Operation Symptoms Possible Cause & Solution Appliance will not Control panel has powered off due to inactivity. operate. • This is normal. Press the POWER (ENCENDIDO/APAGADO) button to turn on the appliance. Appliance is unplugged. • Make sure that the cord is plugged securely into a working outlet. Water supply is turned off.
- Page 37 TROUBLESHOOTING Symptoms Possible Cause & Solution Water leaking Water inlet hose connection is loose at tap or appliance. • Check hoses for leaks, cracks and splits. • Tighten hose connections. House drain pipes are clogged. • The appliance pumps out water very rapidly. Check for water backing up out of the drain pipe during drain.
- Page 38 TROUBLESHOOTING Performance Symptoms Possible Cause & Solution Poor stain removal Proper options are not selected. • Heavier soils and tougher stains may require extra cleaning power. Select the Soak option to boost the cleaning power of the selected cycle. Previously set stains. •...
- Page 39 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
