- Page 1 IP/ PoE Repeater User Manual Model : IP04X 30W High Power PoE Repeater Smart Cabling & Transmission Corp. V1.0...
- Page 2 User Manual IP04X Introduction IP04X is a PoE (Power over Ethernet) repeater that can extend TCP/IP signal and power for an additional 120M with max range up to 300 meters by chaining multiple IP04.. Features Sends PoE signal over a cost-effective CAT5e cable.
- Page 3 User Manual IP04X Link Cable CAT.5e UTP/STP or CAT.6 UTP cable RJ45 Pin Define Link Data Link 1/2, 3/6, 7/8 Power Link 1/2 (+), 3/6(-) End-span...
- Page 4 User Manual IP04X Specification ITEM NO. IP04X Support Compliance IEEE 802.3af, IEEE 802.3at Transmission Distance 120M Network Bandwidth 10/ 100/ 1000Mbps Ports & Interfaces Input 1 x RJ45 Output 1 x RJ45 Power Power Supply IEEE 802.3af (54V, 25.5W) Power Consumption 2.16W 40mA (Max)
