- Page 1 DVI Repeater User Manual Model : DE01ERK DVI CAT5e Extender 70M V1.0 Smart Cabling & Transmission Corp.
- Page 2 DE01ERK Introduction The DE01ERK is a DVI extender that can use a cost-effective Ethernet cable to carry the signal with a transmission distance of up to 70M. With DVI Adaptors, users can transmit high-quality digital video of PC applications thru one cost-effective CAT5/5e to the remote monitor or projector, instead of using short and expensive DVI cables.
- Page 3 User Manual DE01ERK Panel View DE01ET DE01ER Cable To reach long transmission distance and stability, using high quality CAT5E UTP or CAT6 UTP cable is recommended. DO NOT use STP or flat cable, which may cause no video output.
- Page 4 User Manual DE01ERK Specification ITEM NO. DE01ET DE01ER Support Compliance DVI 1.1 Max. Video Resolution 1920 x 1200@60 Hz Max. Transmission Distance 50M at 1920 x 1200 Video Bandwidth 1.65 Gbps Ports & Interfaces Video Input 1 x 25 Pin DVI-D...
