Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
• Colour
• Input power
• Suction Power
• Noise level
• Dustcapacity
• Filtration system
Usability
• Action Radius
• Cord length
• Handgrip
• Accessory storage
Published by Philips Consumer Lifestyle
15/02 Version 1.2
: Magic purple
: 750 W
: 190 W
: 84 dB
: 3 L
: Micro filter
S-bag
: 8 m
: 5 m
: Extra long ergonomic grip
: Accessory holder on
telescopic tube
Printed in the Netherlands
Vacuum cleaner
Weight and dimensions (L x W x H):
• Dimensions of product
• Dimensions packaging
• Weight
ACCESSORIES
• Standard nozzle
: Parquet nozzle
• Additional nozzle
: Mini Turbo brush and
Alma HF nozzle
• Tubes
: Aluminium 2-P telescopic tube
• Accessories
: Crevice nozzle, Small nozzle and
Easy reach tool
REPAIR INSTRUCTION
• No specific issues
OPTIONAL (accessories)
• FC8021/03 : Philips Disposable S-bag
© Copyright reserved
FC8323/09
: 406 x 282 x 220 mm
: 520 x 300 x 290 mm
: 4.2 kg
Subject to modification
Advertisement
Related Manuals for Philips FC8323/09
Summary of Contents for Philips FC8323/09
- Page 1 : 8 m • Cord length : 5 m OPTIONAL (accessories) • Handgrip : Extra long ergonomic grip • FC8021/03 : Philips Disposable S-bag • Accessory storage : Accessory holder on telescopic tube Published by Philips Consumer Lifestyle Printed in the Netherlands ©...
- Page 2 DISASSEMBLY- AND RE-ASSEMBLY ADVISE FC8323/09 • First remove the dust bag. • The 3 screw is hidden under the On/Off pedal (12), to remove the pedal use a screwdriver (see picture). • To replace the wheels (10), first turn the appliance upside down.
-
Page 3: Electrical Diagram
DISASSEMBLY- AND RE-ASSEMBLY ADVISE FC8323/09 • To replace the parkhook (13), first remove Screw C, then • The safety valve assy (21) can be clogged with dust, by pushing the two lips with a screwdriver the parkhook it can be easily taken out and replaced after the can be removed (see picture). -
Page 4: Parts List
PARTS LIST FC8323/09 Service code Description Remark 9965 100 71392 Dustcover assy Magic purple 4322 004 93701 Reusable dustbag 9965 100 52011 Dustbag holder 9965 100 71394 Cover for handle Magic purple 4322 005 28221 Dustbag full indicator (Red) Hare low power... -
Page 5: Exploded View
EXPLODED VIEW FC8323/09... - Page 6 EXPLODED VIEW FC8323/09...
- Page 7 EXPLODED VIEW FC8323/09...
- Page 8 EXPLODED VIEW FC8323/09...
- Page 9 FC8323/09 Version history Version 1.1 : FC8323/09 initial release. Version 1.2 : On page 1 under Accessories Added Alma HF nozzle. In Parts List and Exploded view: Added Pos. 37: 4322 004 26061 Alma HF nozzle Conical 35 mm KC Deep black.
