Speco SG-WM200 Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Weatherproof Mullion Backlit Keypad
(housing with electronics)
SG-WM200
Speco Technologies weatherproof mullion backlit keypad is designed to meet most
residential, commercial and industrial single door access control requirements.
It is a two piece unit that is fully sealed for all environments. The electronics reside in the
protected area.

Features

• Mounts on the narrow mullion of glass
and aluminum doors
• Indoor/Outdoor surface mount applications
• 12 backlit keys
• Sounder
• Weather resistant
• 130 users
• Input trigger for request to exit
• 3 independent relay outputs (5A/250V AC)
• Adjustable time relay for up to 99 seconds for
each relay output, or latched

Specifications

Power . . . . . . . . . . . . . . . . . . . . . .
Acceptable Voltage Variation . . . . . . . .
Power Consumption . . . . . . . . . . . . .
Operating Temperature . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . .
For more information contact us at:
• Rank/Code program administration
• Each output is assignable by code
• Codes can range from 3 to 6 digits
• Unit shuts down for 20 seconds after entering
3 incorrect codes
• Master code can shut down all others as a
temporary lock-out
• Audible function confirmation
• 12/24 Volt – AC/DC operation
• 1 Year Warranty
.AC or DC, from nominal 12V to 24V
.9V DC to 28V DC max., 10V AC to 26V AC max.
.At 12V DC - less than 100m W in standby
Less than 1.4m W max. in operation
At 24V DC - less than 360m W in standby
Less than 3.3W max. in operation
At 12V AC - less than 255m W in standby
Less than 2.3 W max. in operation
At 24V AC - less than 1 W in standby
Less than 5.7 W max. in operation
.-13˚F to 130˚F (-25˚C to +55˚C)
.5 7/8" H x 1 3/8" W x 3/4" D
