Speco SG-100 Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Stainless Steel Indoor Keypad
SG-100
Speco Te ch n o l ogies stainless steel indoor keypad is designed to meet most
re s i d e n t i a l , c o m m e rcial and industrial single door access control re q u i re m e n t s .
The electronics reside in this self-contained unit wh i ch is flush mounted into a
single gang box .

Features

• Flush mount – single gang box
• Self contained electronics package
• Indoor use
• Sounder
• 130 users
• Input trigger for request to exit
• 2 independent relay outputs (5A/250V AC)
• 1 TLT output (5A/250V AC)
• Adjustable time relay of up to 99 seconds for
each relay output, or latched

Specifications

Power . . . . . . . . . . . . . . . . . . . . . . .
Acceptable Voltage Variation . . . . . . . . .
Power Consumption . . . . . . . . . . . . . .
Operating Temperature . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . . .
For more information contact us at:
( rear of unit)
• Rank/Code program administration
• Each output is assignable by code
• Codes can range from 3 to 6 digits
• Unit shuts down for 20 seconds after entering
3 incorrect codes
• Master code can shut down all others as a
temporary lock-out
• Visual/Audible function confirmation
• Tamper switch
• 12/24 Volt – AC/DC operation
AC or DC, from nominal 12V to 24V
9V DC to 28V DC max., 10V AC to 27V AC max.
At 12V DC - less than 160m W in standby
Less than 580m W max. in operation
At 24V DC - less than 480m W in standby
Less than 1.4W max. in operation
At 12V AC - less than 360m W in standby
Less than 1.2 W max. in operation
At 24V AC - less than 1.2W in standby
Less than 2.9W max. in operation
-13˚F to 130˚F (-25˚C to +55˚C)
4 1/2" H x 3" W x 3/4" D (including electronics panel)
