TOOLPRO
18V 2 Speed Drill Driver
Instruction Manual
Important
- Please read these instructions fully before operating or maintaining your Drill driver
These instructions contain important information that will help you get the best from your Drill
driver, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989
After Sales Support
FREE CALL 1300 889 028
EMAIL:salesau@positecgroup.com
CDT218G.1
Advertisement
Related Manuals for ToolPRO CDT218G 1 Series
Summary of Contents for ToolPRO CDT218G 1 Series
- Page 1 TOOLPRO 18V 2 Speed Drill Driver CDT218G.1 Instruction Manual After Sales Support FREE CALL 1300 889 028 EMAIL:salesau@positecgroup.com Important - Please read these instructions fully before operating or maintaining your Drill driver These instructions contain important information that will help you get the best from your Drill driver, ensuring it remains safe to operate.
-
Page 2: Table Of Contents
Contents Safety Information.....................3 In The Box........................8 Accessories.......................8 Operating Instructions....................9 Trouble shooting.....................14 Maintenance......................14 Technical Data......................15 Customer Helpline 1300 889 028... -
Page 3: Safety Information
Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols To reduce the risk of injury, Please read the instruction manual Warning Wear ear protection Wear eye protection Wear dust mask Indoor use only Do not expose to rain or water Do not burn Waste electrical products must not be disposed of with household waste. - Page 4 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
- Page 5 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach.
- Page 6 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
- Page 7 Safety Information Important - Please read these instructions fully before starting assembly Safety Warnings for battery pack a) Do not dismantle, open or shred cells or battery pack. b) Do not short-circuit a battery pack. Do not store battery packs haphazardly in a box or drawer where they may short-circuit each other or be short-circuited by conductive materials.
-
Page 8: In The Box
In The Box Parts Keyless chuck Belt clip Torque adjustment ring Battery pack release button Two-speed gear control On/off switch Forward/Reverse rotation control Sight light Soft grip handle Battery capacity indication Battery pack Accessories Li-ion battery pack Charger Double ends bit Belt clip Customer Helpline 1300 889 028... -
Page 9: Operating Instructions
Operating Instructions Intended Use This tool is intended for driving in and loosening screws as well as for drilling in wood, metal and plastic. NOTE: Before using the tool, read the instruction book carefully. 1. CHARGING PROCEDURE BEFORE PUTTING INTO OPERATION CHARGING THE TOOL OR BATTERY PACK (SEE FIG A) NOTE: a) The battery in your new tool is not charged when it leaves the plant. - Page 10 Operating Instructions 2. INSTALLING AND REMOVING THE BATTERY PACK (SEE FIG B) a) TO REMOVE THE BATTERY PACK Press the Battery Pack Release Button (8) firmly first and then slide the Battery Pack out from your tool. b) TO INSTALL THE BATTERY PACK Slide the fully charged Battery Pack onto the tool with sufficient force until it clicks into position.
- Page 11 Operating Instructions 4. SWITCH LOCK (SEE FIG C) The switch trigger can be locked in the OFF position. This helps to reduce the possibility of accidental starting when not in use. To lock the switch trigger, place the rotation control (b) in the center position. 5.
- Page 12 Operating Instructions 9. TORQUE ADJUSTMENT (SEE FIG E) (Screw driving force of your drill driver) The torque is adjusted by rotating the torque adjustment ring. The torque is greater when the torque adjustment ring is set on a higher setting. The torque is less when the torque adjustment ring is set on a lower setting.
- Page 13 Operating Instructions 11. Battery Capacity Indication Your tool is equipped with Battery Capacity Indication (11). Press the On/Off Switch (9) halfway or fully, the Battery Capacity Indication (11) will light up to show the amount of charge left in the battery. Fuel Gauge Capacity 3 lights...
-
Page 14: Trouble Shooting
Trouble shooting 1. WHY DOES THE DRILL NOT TURN ON WHEN YOU PRESS THE SWITCH? The forward/reverse rotation control, which is on top of the trigger, is positioned in the lock function. Unlock the forward/reverse rotation control by putting it into the required rotation position. -
Page 15: Technical Data
Technical Data Technical Data Table Voltage 18 V No load speed 0-400/0-1450/min Number of clutch positions 18+1 Max torque 30 N.m Chuck capacity 13 mm Charger Protection class Charging time 3-5hr 100-240V~50/60Hz Charger Input Charger Output 10.8--20V 400mA Steel 10mm Max.
