TOOLPRO
18V DRILL DRIVER
Instruction Manual
Important
- Please read these instructions fully before operating or maintaining your drill driver
These instructions contain important information that will help you get the best from your
drill driver, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 1300 889 028
CDT218BWG CDT218BWG.9
After Sales Support
FREE CALL 1300 889 028
EMAIL:salesau@positecgroup.com
Advertisement
Related Manuals for ToolPRO CDT218BWG
Summary of Contents for ToolPRO CDT218BWG
- Page 1 TOOLPRO 18V DRILL DRIVER CDT218BWG CDT218BWG.9 Instruction Manual After Sales Support FREE CALL 1300 889 028 EMAIL:salesau@positecgroup.com Important - Please read these instructions fully before operating or maintaining your drill driver These instructions contain important information that will help you get the best from your drill driver, ensuring it remains safe to operate.
-
Page 2: Table Of Contents
Contents Safety Information.....................3 In The Box........................9 Accessories.......................9 Operating Instructions....................10 Trobule Shooting...................... 16 Maintenance......................16 Technical Data......................17 Customer Helpline 1300 889 028... -
Page 3: Safety Information
Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols To reduce the risk of injury, user must read instruction manual Warning Wear eye protection Wear ear protection Indoor use only Wear dust mask Do not burn Batteries may enter water cycle if disposed improperly, which can be hazardous for ecosystem. - Page 4 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
- Page 5 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings have the switch on invites accidents. d) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. e) Dress properly.
- Page 6 Safety Information Important - Please read these instructions fully before starting assembly General Power Tool Safety Warnings clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
- Page 7 Safety Information Important - Please read these instructions fully before starting assembly Safety Warnings for battery pack a) Do not dismantle, open or shred cells or battery pack. b) Do not short-circuit a battery pack. Do not store battery packs haphazardly in a box or drawer where they may short-circuit each other or be short-circuited by conductive materials.
- Page 8 Safety Information Important - Please read these instructions fully before starting assembly GeneralSafety Warnings WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. - This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person...
-
Page 9: In The Box
Keyless Chuck Battery Pack Release Button Torque Adjustment Ring LED light Two-speed Gear Control On/Off Switch Forward/Reverse Rotation Control Battery Capacity Indicator Soft Grip Handle Belt Clip Accessories CDT218BWG CDT218BWG.9 Battery Pack Charger Belt Clip Customer Helpline 1300 889 028... -
Page 10: Operating Instructions
Operating Instructions NOTE: Before using the tool, read the instruction book carefully. Intended Use This tool is intended for the fastening and loosening of bolts, nuts and various threaded fasteners. This tool is not intended for use as a drill. BEFORE PUTTING INTO OPERATION 1. - Page 11 Operating Instructions C) CHARGING INDICATOR This charger is designed to detect some problems that can arise with battery packs. Indicator lights indicate problems (see table below). If this occurs, insert a new battery pack to determine if the charger is OK. If the new battery charges correctly, then the original pack is defective and should be returned to a service center or recycling service center.
- Page 12 Operating Instructions 2. REMOVE OR INSERT BATTERY PACK (SEE FIG. B,C) Press the battery pack release button and remove the battery pack from the tool. After recharge slide the battery pack into tool’s battery port. A simple push and slight pressure will be sufficient.
- Page 13 Operating Instructions 3. REVERSIBLE (SEE FIG. F1, F2) Forward rotating: push the forward/reverse rotation control to the left (the drill points away from you). It is used for drilling and screw driving. Reverse rotation: push the forward/reverse rotation control to the right (the drill points away from you).
- Page 14 Operating Instructions CLOSE OPEN 6. TORQUE ADJUSTMENT (SEE FIG I) The torque is adjusted by rotating the torque adjustment ring. The torque is greater when the torque adjustment ring is set on a higher setting. The torque is less when the torque adjustment ring is set on a lower setting.
- Page 15 Operating Instructions 8. USING THE SIGHT LIGHT To turn on the light, press the on/off switch and make sure the forward/reverse rotation control is on right/left position. When you release the on/off switch, the light will be off. LED lighting increases visibility-great for dark or enclosed area. LED is also a battery capacity indicator.
-
Page 16: Trobule Shooting
Trouble Shooting 1. WHY DOES THE DRILL NOT TURN ON WHEN YOU PRESS THE SWITCH? The forward/reverse rotation control, which is on top of the on/off switch, is positioned in the lock function. Unlock the forward/reverse rotation control by putting it into the required rotation position. -
Page 17: Technical Data
Technical Data Technical Data Table Type: CDT218BWG CDT218BWG.9 (CDT -designation of machinery, representative of Drill) CDT218BWG CDT218BWG.9 Voltage No load speed 0-500/0-2000 /min Number of clutch positions 18+1 Max torque 60N.m Chuck capacity 13mm Steel 13mm Max. drilling capacity Wood...
