Speco SP-5MA/T Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Multi-Application (MA) Series
5.25" or 6.5" 70/25V Commercial Speaker System
Speco Technologies' Multi-Application (MA) Series was designed with the focus of
making the contractor's work as easy and time-efficient as possible.
Our all-in-one unit, pre-assembled with a back can and mounted transformer,
features a quick flip 70 or 25 Volt selector switch and an easy select transformer
wattage dial featuring the choice of 8 or 9 individual wattage tap settings covering
your complete range of needs.
This fire-retardant, ABS unit also comes with insulated wires and has an attached
metal safety loop and easy mount tabs for securing the unit.
The MA Series is the ideal all purpose, value sound solution covering a wide range
of applications in commercial sound, and with a furnished 8 ohm tap selector, can
be kept readily on hand to meet all your unexpected sound installation needs.
Specifications
Woofer
Tweeter
Frequency
Power
Sensitivity
Impedance
Weight
Transformer
Transformer Settings
In-Ceiling Bracket Supports
For more information contact us at:
SP-5MA/T 5.25" 70/25V
Commercial Speaker System
5.25" Polypropylene with
Rubber Surround
1" Mylar Tweeter
57Hz –20kHz
30 Watt RMS/ 60 Watt Max
87 db 1w/1m
8 ohms
4.5 lbs.
70/25 Volt
30, 15, 7.5, 5, 2.5, 1,
.50, .25, 8ohm
BRC-6F
SP-6MA/T Shown
SP-6MA/T 6.5" 70/25V
Commercial Speaker System
6.5" Polypropylene with
Rubber Surround
1" Mylar Tweeter
34Hz –20kHz
40 Watt RMS/ 80 Watt Max
88 db 1w/1m
8 ohms
5.5 lbs
70/25 Volt
40, 30, 15, 7.5, 5, 2.5, 1,
.50, .25, 8ohm
BRC-8F
