Speco SP6MAT Specification Sheet

Multi-application (ma) series 5.25” or 6.5” 70/25v commercial speaker system

Advertisement

Quick Links

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Multi-Application (MA) Series
5.25" or 6.5" 70/25V Commercial Speaker System
Speco Technologies' Multi-Application (MA) Series was designed to make the contractor's work
as easy and time-efficient as possible.
Our all-in-one unit, pre-assembled with a back can and mounted transformer, features a quick flip
70 or 25 Volt selector switch and an easy select transformer wattage dial featuring the choice of
8 or 9 individual wattage tap settings covering your complete range of needs.
This fire-retardant, ABS unit also comes with insulated wires and has an attached metal safety loop
and easy mount tabs for securing the unit.

Specifications

Woofer
Tweeter
Frequency
Power
Sensitivity
Impedance
Weight
Transformer
Transformer Settings
In-Ceiling Bracket Supports
Dimensions
Mounting Dimensions
For more information contact us at:
SP5MAT 5.25" 70/25V
Commercial Speaker System
5.25" Polypropylene with
Rubber Surround
1" Mylar Tweeter
57Hz –20kHz
30 Watt RMS/ 60 Watt Max
87 db 1w/1m
8 ohms
4.5 lbs.
70/25 Volt
30, 15, 7.5, 5, 2.5, 1,
.50, .25, 8ohm
BRC6F
9.5" Dia. x 6" Depth
8 3/8" Diameter
SP6MAT Shown
SP6MAT 6.5" 70/25V
Commercial Speaker System
6.5" Polypropylene with
Rubber Surround
1" Mylar Tweeter
34Hz –20kHz
40 Watt RMS/ 80 Watt Max
88 db 1w/1m
8 ohms
5.5 lbs
70/25 Volt
40, 30, 15, 7.5, 5, 2.5, 1,
.50, .25, 8ohm
BRC8F
11" Dia. x 7.5" Depth
9 7/8" Diameter
