Speco CSi/ DMS-3TS Specification Sheet

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Mini 3-Way Speaker System with Built in
70/25 Volt Transformer
DMS-3TS
Features
3-Way Polypropylene Speaker Construction . . .3 Cone drivers to capture full range of
Aluminum Die-Cast Metal,
Hermetically-Sealed Casing . . . . . . . . . . . . . . . . . .Protects internal speaker components from
Fine Mesh Aluminum Grille . . . . . . . . . . . . . . . . . .Protects external speaker face from the
Multiple Wattage Settings . . . . . . . . . . . . . . . . . . .Allows individual wattage setting
Rotary Wattage Dial . . . . . . . . . . . . . . . . . . . . . . . .Quick and easy wattage tap adjustments

Specifications

Woofer . . . . . . . . . . . . . . . . . . .
Tweeter . . . . . . . . . . . . . . . .
Midrange . . . . . . . . . . . . . . . . . .
Frequency Response . . . . . . . . . . .
Power Rating . . . . . . . . . . . . . . . .
Impedance . . . . . . . . . . . . . . . . .
Transformer . . . . . . . . . . . . . . . .
Wattage Settings . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . .
Sold Individually, Available in White (DMS-3TSW)
Removable mounting bracket
Mounting Hardware
For more information contact us at:
Benefits
frequencies including crystal clear midrange
exposure to the elements
elements and prevents rust
to application
4" Air Suspension Polypropylene cone
1" Dome Tweeter
2" Polypropylene Cone
55Hz-20kHz
30 Watts RMS/ 50 Watts Max
8 Ohms
Built-in 70 and 25 Volt
15, 7.5, 4, 2, 1 Watts
7 3/8" H x 4 3/8" W x 4 1/8" D
Package Includes:
Speaker wire
