Microprocessor controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
&7
Operating & Service Instructions...
HP7R
Microprocessor Controller
Dealer & Service Version
Not for Distribution to Owners
th
2737 24
Street North
St. Petersburg, FL 33713
800-786-7751
www.aquacal.com
1/7/04
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP7R and is the answer not in the manual?

Questions and answers

Related Manuals for Aquacal HP7R

Summary of Contents for Aquacal HP7R

  • Page 1 &7 Operating & Service Instructions... HP7R Microprocessor Controller Dealer & Service Version Not for Distribution to Owners 2737 24 Street North St. Petersburg, FL 33713 800-786-7751 www.aquacal.com 1/7/04...
  • Page 2 1-800-786-7751 NOTES ___________________________________________________________________________________ __________________________________________________________________________________ ___________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ ___________________________________________________________________________________ __________________________________________________________________________________ ___________________________________________________________________________________ _________________________________________________________________________________ __________________________________________________________________________________ ________________________________________________________________________________________ ___________________________________________________________________________________ ____________________________________________________________________________________ _________________________________________________________________________________ __________________________________________________________________________________ _________________________________________________________________________________ __________________________________________________________________________________...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS QUICK START & STOP ------------------------------------------------- 04 HEATER CONTROLS-------------------------------------------------- 06 Control Panel Layout ----------------------------------------------- 06 Buttons, Lights, and Display -------------------------------------- 06 Operational & Programming Codes -------------------------------- 07 Level-1 (Owner-Operator) Programming (complete) ------------- 08 CONTROLS CONFIGURATION & ADJUSTMENTS ---------------------- 12 Level-2 (dealer-service) Programming ---------------------------- 12 1.

  • Page 4: Quick Start & Stop

    HEATING- QUICK START & STOP Note to Dealer/Installer: This, and the “Owner Level Programming” sections were originally writ- ten for use by the home owner/operator. As such, much of the language will be owner-directed. The intent of this section is to provide rapid access to very basic operational information. Indi- viduals who will be routinely using, installing, maintaining, and servicing the heat pump, are strongly encouraged to read this entire manual.
  • Page 5 HEATING-QUICK START & STOP (continued): 3. To Begin Heating: A. Verify MODE is set to: HEAT (HEA); then, depending on which body of water is to be heated, use the POOL / SPA selector key to select POOL or SPA. B.

  • Page 6: Heater Controls

    HEATER CONTROLS Control Panel Layout PPEARANCE ARIES BY ODEL Control Buttons, Indicator Lights, & Display AS INDICATED BY CIRCLED NUMBERS 1) POOL / SPA SELECTOR – Selects either pool or spa thermostat. 2) COOLING INDICATOR LIGHT – Indicates unit is cooling. (Note: this light nonfunctional with heat-only models.) 3) UP ARROW –...

  • Page 7: Operational & Programming Codes

    CFO..Call Flex Options. This is a programming entry point; when used in conjunction with an AquaCal Call/Flex add on kit, permits the use of CALL or FLEX options. FS..Heater in Defrost Mode (Applicable to Heat-Only Units, only). This code appears as a normal display during periods of lower air temperatures.

  • Page 8: Level-1 (Owner-Operator) Programming (Complete)

    HEATER CONTROLS...continued Start Up & Setting Operating Controls Owner-Level Programming Instructions (Complete) Covered within this section are features and settings typically accessed first by the installer, and then remaining accessible by the end user (the owner). These features reside at the Level-1 access point within the microprocessor.
  • Page 9 HEATER CONTROLS...continued Start Up & Setting Operating Controls Owner-Level Programming Instructions... continued: . Selecting Pool/Spa Thermostat Settings: A. Press the [POOL/SPA] key to toggle between the pool and the spa temperature set points. B. The pool/spa LED indicator lights, located to the left of the temperature display, will confirm the selected set point.
  • Page 10 HEATER CONTROLS...continued Start Up & Setting Operating Controls Owner-Level Programming Instructions... continued: 8. User Lock Code Option [ULC]...continued: A. Selecting ULC Option: 1) Press either the UP or DOWN ARROW keys; if “LOC” is momentarily displayed flowed by “0”, the ULC feature is enabled. If “0” displays proceed to “6)” of this section; otherwise, see number “2,”...
  • Page 11 [LOC] (Service Lock Code). C. For further information, please refer to Call-Flex installation instructions, shipped with the Call-Flex kit. For additional copies of these instructions, contact the AquaCal Customer Support (800-786-7751). (End... Owner-Level Programming Instructions)

  • Page 12: Controls Configuration & Adjustments

    Generally speaking, the installer’s main focus within Level-2 programming will be in configuring for external controller compatibility. And, unless instructed to do otherwise by the AquaCal Technical Support Group, the installer should not adjust sensor calibration or dead-band values.

  • Page 13: Time Delay

    Controls Configuration & Adjustments... Level-2 Microprocessor Programming... continued: 2. Time Delay [dEL]: A. With the [dEL] (4 minute time delay) code message displayed use the [UP] or [DOWN] arrow key to select either “1” to allow the time delay to remain active or “0” to deactivate the time delay.

  • Page 14: Defrost Sensor Calibration

    Controls Configuration & Adjustments... Level-2 Microprocessor Programming... continued: 4. Water Sensor Calibration... continued: C. Follow the steps 1, A through 1, D to enter the service menu. Once [dEL] is displayed, press the [POOL/SPA] key until the display shows [tSC] (Water Temperature Calibration). Using either the [UP] or [DOWN] arrow keys, calibrate the water temperature sensor by increasing or decreasing the numeric value displayed to match the measured water temperature.

  • Page 15: Spa Dead Band Differential (And Adjustment)

    Controls Configuration & Adjustments... Level-2 Microprocessor Programming... continued: 5. Defrost Sensor Calibration... continued: G. Once the correct temperature value has been selected, not pressing any buttons for 15-seconds will allow the controller to save the selection and return to the normal operating mode.

  • Page 16: Changing Service Lock Code & "Back Door" Entry

    Connecting External Controllers • See document entitled: “Connecting External Controllers to AquaCal Heat Pumps”; this document is shipped with every AquaCal heater. For extra copies, contact AquaCal Customer Support (800-786-7751); request literature piece: “LTP0050.” • For Call-Flex option, reference instructions received with the Call-Flex kit.

  • Page 17: Level-2 Set Up & Calibration Codes

    Controls Configuration & Adjustments... Microprocessor Level-2 Set Up & Calibration Codes Service Adjustable Parameters Code Description Factory Setting Range [LOC] Service Lock Code 00-99 [dEL] 4-minute Delay on Make 0 / 1 [JAO] External Controller Interface 0 / 2 / 3 [FS2] Flow Switch/Auto T-Stat Switching 0 / 1...

  • Page 18: Troubleshooting Using Displayed Codes

    Then, if after working through site-related issues the heater is still not functioning correctly, the Service Representative will offer to set up a service visit. As necessary, please Contact AquaCal Customer Support Group (800- 786-7751).

  • Page 19: Mode Jumper And Positioning

    Microprocessor Mode Jumper Positioning Mode Jumper Explained The HP7R microprocessor is designed to operate as a Heat-Only or a Heating & Cooling controller. The selection between the two choices is made through the positioning of a mode jumper contained on the microprocessor board. The position of the jumper is set at the factory, and is dependant upon the design of the heater being controlled.
  • Page 20 Controls Configuration & Adjustments... Microprocessor Mode Jumper Positioning... continued:...

  • Page 21: Defrost Systems (Described And Explained)

    Controls Configuration & Adjustments... Defrost Systems- Described DEFROST CYCLE (HEAT ONLY UNITS): The microprocessor controller monitors the heater’s air-coil temperature, minimizing air-coil freeze- up during cooler weather conditions. If the controller senses air-coil temperatures conductive to mak- ing ice, the heater’s compressor operation is interrupted while the fan is allowed to continue in opera- tion.
  • Page 22 2737 24th St. North St. Petersburg, FL 33713 1-800-786-7751...
