- Page 1 B89055 Vitruvian Infiltration Pump Service Manual...
-
Page 2: Table Of Contents
1. Servicing Your Pump…………………………..pg 3 2. Pump Layout………………………………………pg 4 - 6 2. Opening Pump Case……………………………pg 7 3. Troubleshooting Guide..……………………..pg 8 4. Pump Head Replacement.…………………..pg 9 Table of 5. Display Board Replacement.………………..pg 10 6. Fuse Replacement.………………….…………..pg 11 Contents 7. Pneumatic Switch Replacement.…….pg 12-14 8. -
Page 3: Servicing Your Pump
Servicing Your Pump Before servicing your pump, please call Black & Black to help troubleshoot your issue and decide, if necessary, what replacement parts you may need. Please have your pump serial number on hand when you call in. It is located on the back lower right corner of the pump and starts with “P1xxx”. -
Page 4: Pump Layout
Front of Pump 25-3023 Rev: None 3/20/2020... - Page 5 Back of Pump 25-3023 Rev: None 3/20/2020...
- Page 6 Inside of Pump Motor Pneumatic Switches Power Supply 25-3023 Rev: None 3/20/2020...
-
Page 7: Opening Pump Case
Opening Pump Case To service parts inside the pump, follow the instructions on page 9 to remove the pump head. Then remove 6 screws from the outside of the case as shown below and lift the cover away from the base of the pump. Use caution as a ribbon cable connects from the base to the display PCB on the inside of the cover. -
Page 8: Troubleshooting Guide
Troubleshooting Guide Problem Possible Causes Solution Pump head not Damaged Pump Head Replace Pump head (pg 9 ) rotating Replace Display Board (pg 10 ) Display board damaged No Display Plug ribbon cable back into Ribbon cable disconnected from display board display board (pg 10 ) Power cord not plugged in Connect power cord... -
Page 9: Pump Head Replacement
Pump Head Replacement To replace the pump head – Remove old pump head by unscrewing the 2 tightening screws shown below and pulling the pump head horizontally towards you to remove. To install new pump head, line up pump head notch with grommet on motor inside of pump and carefully push in. -
Page 10: Display Board Replacement
Display Board Replacement Ribbon cable Control Remove 4 sets of cables from display board knob Prime Button Reverse Switch Remove 4 screws from display board. Install new display board, secure 4 screws back on board, plug 4 sets of cables back on board according to picture above. -
Page 11: Fuse Replacement
Fuse Replacement Open fuse slot by pulling on tab on top of slot Remove damaged fuse, and replace with good fuse. 25-3023 Rev: None 3/20/2020... -
Page 12: Pneumatic Switch Replacement
Pneumatic Switch Replacement Disconnect wires from damaged pneumatic switch. Remove Remove damaged switch tightening nut Remove lock nut 25-3023 Rev: None 3/20/2020... - Page 13 Pneumatic Switch Replacement cont. Secure Insert new tightening nut switch Secure lock nut 25-3023 Rev: None 3/20/2020...
- Page 14 Pneumatic Switch Replacement Connect wires back to new switch 25-3023 Rev: None 3/20/2020...
-
Page 15: Replacement Parts List
Replacement Parts List Part Number Description 58-9056A LED/Display Board 58-9026P MOMENTARY AIR SWITCH 89026P HARD FOOT PEDAL, 10FT TUBING 89032 HOSPITAL GRADE POWER CORD (18/3 10 FT) 58-9055Q POWER SUPPLY 58-9055U CERAMIC FUSE 25-3023 Rev: None 3/20/2020... -
Page 16: Contact Us
Contact us Please contact Black & Black Surgical with any questions! Email: info@blackandblacksurgical.com Phone: 770-414-4880 25-3023 Rev: None 3/20/2020...
