Quatech QSC-100 User Manual page 23

INSTRUCTIONS:
------------------------
Press keys listed in the menu at the bottom of the screen.
This program only displays information. It cannot make changes.
Numbers preceeded by "0x" are hexadecimal.
PCI BIOS detected, version 2.10
Quatech PCI adapters detected
---------------------------------------------
QSC-100 Four-port RS-232 adapter
Uses IRQ 11
Base addr 1 = 0xff80
_
Q - Quatech PCI adapters
N - Other PCI devices
X - EXIT
Figure 14 shows the Expert Mode display for the QSC-100 after the "Q" key has been
pressed. The information from the Basic Mode display is presented along with more details such
as the Vendor and Device IDs, PCI Class Code, size of memory and I/O regions, etc. Pressing
the "N" key will show similar information for all non-Quatech PCI devices in the system,
including those devices integrated on the motherboard. In this example, the "Base addr 0"
resource is reserved.
Quatech QSC-100 User's Manual
Quatech PCI Configuration Information Display Software
Version 1.00
I/O
Figure 14 --- QTPCI.EXE Basic Mode display
