- Page 1 OTTO’S GRILL STAND XL ASSEMBLY INSTRUCTIONS Grill stand for The Otto Grill with slide-out gas bottle drawer and additional storage space...
-
Page 2: Welcome To The Family
WELCOME TO THE FAMILY... - Page 3 The spacious counter top can easily be wiped clean due to it also being made of high-grade stainless steel. The best part of the Otto Grill Stand XL is the gas bottle storage. With a slide-out drawer the gas bottle storage is easily accessible for installation and maintenance.
-
Page 4: Scope Of Delivery
SCOPE OF DELIVERY Here is a list of parts that are exemplary for your Grill Stand XL. Quickly check that all the pieces are there and use the screws supplied. 40x M5 X 12 Screw 16x M6 X 16 Screw... - Page 5 1x Cross Brace 1x Cross Brace Top 4x Adjustable Castor 1x Side Wall Left 2x Rubber Protect Ring 1x Counter Top 1x Toeboard Right 1x Toeboard Left 2x Door Hinges 1x Toeboard Front 1x Toeboard Back 1x Door 1x Drawer Front 32" 3x Drawer Front 16"...
- Page 6 ASSEMBLY CORE A 5 x Before installing the side walls or middle panel, we recommend first installing the drawer slides.
- Page 7 Snap the soft-close mechanism of the rail forward to tighten the rear two screws. B 32 x Repeat on the opposite side.
- Page 8 A 5 x Save one screw for later. A 5 x...
- Page 9 A 3 x A 1 x A 7 x...
- Page 10 Be sure to place the washers on the screws as shown here in order C 16 x to ensure proper faste- ning of the castors. For mobile use these mounting holes (1) and for stationary installati- on use these mounting holes (2).
- Page 11 A 3 x A 4 x...
- Page 12 A 2 x...
- Page 13 H 8 x It’s best to install the door hinges, particu- larly the lower hinge, before the gas bottle drawer.
- Page 14 ASSEMBLY GAS BOTTLE DRAWER A 4 x A 2 x B 4 x Repeat on the opposite side.
- Page 15 Be sure the lock is in the in the “up” position and secured before inserting the drawer completely.
- Page 16 Be sure to secure the drawer by placing the locking cylinder in the hole in the floor.
- Page 17 ASSEMBLY A 5 x...
- Page 18 ASSEMBLY DOOR B 2 x Be sure to break out the cover on the side of the door that corre- sponds to the opening direction. H 4 x...
- Page 19 Loosen the thumb screw and allow the safety support fall un- til the foot is on the ground. Adjust the foot as needed by screwing in up or down.
- Page 20 ASSEMBLY DRAWER 16" AND 32" B 18 x...
- Page 21 B 6 x...
