- Page 1 GRILL DRAWER OPERATING MANUAL Convenient grate and drip tray drawer made out of stainless steel Praktischer Rost- und Fettfangschalenauszug aus Edelstahl...
- Page 2 WELCOME TO THE FAMILY...
- Page 3 GREAT SLIDER Otto Wilde congratulates you on the purchase of Otto’s Grill Drawer. With the Grill Drawer you’ll no longer need to lift the grate out of the grill. Using the handy multi- tool, you can easily pull out the drawer, flip your food and push the drawer back in.
-
Page 4: Scope Of Delivery
SCOPE OF DELIVERY Here is a list of acces- sories that belong to the Grill Drawer. Quickly check that all the parts are there and use the screws supplied. Hier ist eine Zubehörliste, die zum Rostauszug ge- hören. Check die Liefe-... - Page 5 PREPARATION Place your Otto Grill on a suitable table or work- bench. Stelle Deinen O.F.B. auf einen geeigneten Tisch bzw. eine Werkbank Open the buckles on the back of the unit. Öffne die Schnallen an der Rückseite des Gerätes. Remove the top from the base and remove the grill grate and grease tray.
- Page 6 DISASSEMBLY Before starting the as- sembly, remove the front cover from the drawer by unscrewing the two knurled screws. Bevor die Montage beginnt, löse das Schutz- blech vom Auszug, indem Du die zwei Rändelschrau- ben abschraubst. KEEP THE SCREWS IN A SAFE PLACE! BEWAHRE DIE SCHRAUBEN GUT AUF!
- Page 7 ASSEMBLY Turn the base onto its left side. Drehe die Base auf die linke Außenseite. Release the brake, on the back of the base, by turn- ing it CCW. Slide the lower lever arm to a position as shown in the diagram and close the brake by turning it CW.
- Page 8 Place the left guide rail on the side wall of the base, so that the lower hole of the rail is centered over the threaded hole of the lower lever arm. Lege die linke Führungs- schiene so auf die Seitenwand der Base, dass das untere Loch der Schiene mittig über der Gewindebohrung des...
- Page 9 Turn the base back to the horizontal position. Drehe die Base zurück in die waagerechte Position. To assemble the frame of the drawer, position the rollers attached to the ends over the openings of the guide rails. Lift the frame at the front. Um den Rahmen des Auszuges zu montieren, bringe die an den Enden...
- Page 10 Place a roller block on both sides in the openings of the guide rails and fas- ten the roller blocks to the guide rails with the roun- ded head screws using the holes provided. Setze auf beiden Seiten einen Rollenbock in die Ausnehmungen der Führungen und verschrau- be die Rollenböcke und...
- Page 11 Verkantungen kommen, die Du durch erneutes Raus- play. This can, occasionally, cause slight jamming, which can und Reinfahren mit leicht angepasstem Winkel beheben be remedied by moving the Grill Drawer in and out again at a kannst. slightly adjusted angle.
- Page 12 Otto Wilde Grillers GmbH Benzenbergstr. 44 40219 Düsseldorf Share your grill experience with us! +49 (0) 211 542 130 30 service@ottowilde.de www.ottowildegrillers.com...
