INSTRUCTION MANUAL
ELIXIR-T-UNI
Compact Vibrating Fork
Version 2.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELIXIR-T-UNI and is the answer not in the manual?

Questions and answers

Related Manuals for Sapcon ELIXIR-T-UNI

Summary of Contents for Sapcon ELIXIR-T-UNI

  • Page 1 INSTRUCTION MANUAL ELIXIR-T-UNI Compact Vibrating Fork Version 2.4...

  • Page 2: Table Of Contents

    Elixir-T-Uni ........
  • Page 3 Output of AS-Interface ..........® Sapcon Instruments Pvt.Ltd.
  • Page 4 AS-i Configuration ..........® Sapcon Instruments Pvt.Ltd.

  • Page 5: Revision History

    • Copyright: All content on this document, such as text, graphics, logos and images is the property of Sapcon Instruments Pvt. Ltd. The selection, arrangement and presentation of all materials on this document and the overall design of this document is the exclusive property of Sapcon Instruments Pvt.

  • Page 6: Introduction

    Hygienic finish with 0.8 Ra available 1 Introduction • No calibration required at site, easy to install Elixir-T-Uni is a vibrating fork level switch used for level detection in storage tanks, mixing container and • Compact in size pipelines in all kinds of liquid which do not react with •...

  • Page 7: Electrical Specifications

    Probe Length 68 mm, 105 mm, 125 to 1000 mm Process Temperature Up to Sensing Fork Material SS 316 Fork Finish • Hygienic Fork • Standard Fork Pressure Up to 10 Bar Table 3: Mechanical Specifications ® Sapcon Instruments Pvt.Ltd.

  • Page 8: Installation Guidelines

    Connect negative terminal to Pin no. 1 of the device. power supply. • Connect fuse between positive terminal and Pin no. 2 Note: Elixir-T-Uni does not have any keys to oper- of the device. ate.The Fail-safe feature has been implemented in •...

  • Page 9: For M-12 Connector

    110 ◦ (300 MiliSec- • Fork is Covered and Fail-safe is High onds) • Fork is Uncovered and Fail-safe is Low Blue LED Temperature Glows Per- goes above 120 ◦ manently Table 4: Error Indication ® Sapcon Instruments Pvt.Ltd.

  • Page 10: For As-Interface Module

    D2 & D3 are not engaged. polling Communication Speed 167 kbits/sec Max. Data Size 8 bits Table 6: AS-i Configuration 13.4 Electrical Connections Please refer to the Figure 10 & 11 for electrical connec- tions of AS-Interface Module. ® Sapcon Instruments Pvt.Ltd.

  • Page 11: Setting Up As-Interface

    ASi-3. AS-Interface can set up easily using a PLC with AS- Interface bus input. Follow these steps for setting up the AS-Interface bus with Elixir-T-Uni: • Set Unique Bus ID: Default set address(extended) is 1a (HEX) & can be change using ASi programming unit by selecting default address zero.

  • Page 12: Order Code

    User Manual & Datasheet V 2.4 15 Order Code Product ETU: Elixir-T-Uni: Compact tubular vibrating fork level limit switch (suitable for all kinds of liquids having viscosity upto 10,000 cP and density greater than or equal to 0.7gm/cc) Type I : Integral (sensor in same unit)
