Summary of Contents for Endorphines COCKPIT 2
- Page 1 COCKPIT 2 / 1U...
-
Page 2: Table Of Contents
CONTENT WARRANTY ............................. 3 VISIT US ..............................3 INTRO ..............................4 CONNECTING THE POWER ........................4 TECHNICAL SPECIFICATIONS ........................4 OVERVIEW ............................... 4 INTERFACE .............................. 5 REAR CONNECTIONS ..........................7 COMPRESSOR MODES ..........................9 CREDITS ..............................10 COMPLIANCE............................10... -
Page 3: Warranty
WARRANTY 1year warranty guaranteed from the product's purchase date in case of any manufacturing errors or other functional deficiencies during runtime. The warranty does not apply in case of: damage caused by misuse mechanical damage arising from careless treatment (dropping, vigorous shaking, mishandling, etc.) damage caused by liquids or powders penetrating the device heat damage caused by overexposure to sunlight or heating electric damage caused by improper connecting The warranty covers replacement or repair, as decided by us. Please contact us via email for a return authorization before sending anything. Shipping costs of sending a module back for servicing is paid by the customer. Device complies with all EU regulations concerning RoHS leadfree manufacturing and WEEE disposal. VISIT US https://endorphin.es https://youtube.com/user/TheEndorphines https://facebook.com/TheEndorphines https://twitter.com/endorphin_es https://www.instagram.com/endorphin.es/ https://www.modulargrid.net/e/modules/browser/vendor:167 For technical requests: support@endorphin.es For dealer / marketing inquiries: info@endorphin.es ENDORPHIN.ES is a registered trademark. It is doing business as FURTH BARCELONA, S. L. (EU VAT ID: ES B66836487) ... -
Page 4: Intro
INTRO Cockpit 2 and Cockpit 1U is a four-channel stereo performance mixer with mutes, on-board compressor and external sidechain control voltage option (3 modes) to add dynamics to your Available in 3U 6hp and 1U 24hp versions with some design differences. -
Page 5: Interface
INTERFACE ... - Page 6 ROTARY ENCODERS / FADERS 1. are four endless encoders with detents and a push button used to adjust the volume of each channel, acts as mute buttons and set the sidechain amount per channel. Turning the encoder clockwise will make the channel's level higher and turning it counter-clockwise will attenuate the channel off to full silence. Since encoder's rotation is endless, it doesn’t have a line that shows its current position to understand the level of the channel.
-
Page 7: Rear Connections
MASTER VOLUME KNOB: 8. adjusts the final mix output level. STEREO OUTPUT: 9. final mix stereo output, with enough current to drive a wide range of headphones. We recommend using either a stereo 3.5mm TRS cable or a stereo splitter cable available at our Merch store: https://endorphines.myshopify.com/products/ysplitteradapter35mmtrsstereo tolr35mmtsmono REAR CONNECTIONS Both 1U and 3U versions feature extra rear connections, that are either used for daisy chaining multiple modules together to act as one big mixer or to wire the Inputs / Outputs to either other modules or ¼ inch TRS outputs via the Intellijel Jacks IO v2 board. COCKPIT 2 / 3U: ... - Page 8 4 MONO/STEREO JUMPERS 1. that set if the chosen audio input accepts Stereo or Mono sources. Each jumper may be in two positions. For example S– CH1–M. When jumper set on pins pair S–CH1, then the input of Channel 1 is a full stereo input that will accept and adjust left and right channels and output them to the left and right channel of your speakerphones. When the jumper set on CH1–M pair, Channel 1 input accepts mono signals only, ignoring the signal that may occur from the ring (right), and that left signal will appear in the left out and then exactly doubled in your right out. When no jumpers are installed, then absolutely no right signal from that channels (whenever stereo or mono plug inserted) will appear in your right outputs. DAISY CHAIN MASTER / SLAVE PINS 2. are pins used for daisy chaining multiple modules together to create a bigger mixer system using Dupont FemaleFemale cables. Those cables are not included. You may easily find them e.g. from Amazon or your local dealers. Everything connected to Master (AUX) will be mixed with the rest 4 channels. Slave out is literally the is post master volume knob audio output. For merging two Cockpit mixers together, connect the Slave (OUT) pins on Cockpit #2 to Master (AUX) pins of Cockpit #1. Cockpit #1 is a main mixer and its output will have all 8 channels from both Cockpits mixed together. GROUND PINS 3. – pair of ground connectors to be used for interconnecting the modules in case you need them. +10V POWER OUTPUT 4. – not used 10V POWER OUTPUT 5. – not used POWER CONNECTOR 6. is 10 pin typical +/12V eurorack power connector. COCKPIT 1U version: ...
-
Page 9: Compressor Modes
MIX OUT 2. is post master volume knob audio output, compatible with other Mix Bus modules. STEREO BALANCED LINE OUT 3. is 6 pin connector for the Intellijel Jacks IO v2 board. Let’s you route the final post master volume knob output straight to the TRS jacks on the Intellijel cases. POWER CONNECTOR 4. is 10 pin typical +/12V eurorack power connector. COMPRESSOR MODES The built in compressor features 3 different modes of dynamic processing of audio signals. To switch different modes, hold press all 4 encoders for longer than 1 second until you see the SIDECHAIN LED (7) blink either 1, 2 or 3 times showing the selected mode. On every startup that LED blinks same amount of times reminding the selected mode. Selected mode automatically saves after a few seconds of idle Cockpit use. DUCKING WITH CV: 1. The input of the COCKPIT accepts unipolar CV from 0 to approximately +5V. Everything that goes above +5V is being saturated, and everything that is below zero will be cut off. The SIDECHAIN KNOB adjusts the level of ducking. Adjust it to the desired pumping level/intensity. The blue LED near that knob shows the amplitude of the input signal and lights up when the ducking level increases. TIPP: When no plug is inserted into the sidechain jack, the sum of all four channels is sent to the sidechain input of the ducking compressor. That connection may seem a bit experimental (since the channel generates a CV envelope from the full mix and it may sound more like amplitude modulation), however at some point it may bring interesting results. DUCKING WITH AUDIO: 2. The sidechain input is amplified by approx. 10 ... -
Page 10: Credits
(falling ramp). That envelope has instant (zero) attack and the decay time is defined by the sidechain knob. Time of decay varies from 10ms to 10 seconds and at full CCW knob position there is no effect applied. This mode works great if you don’t have an extra envelope in your system, but also because you can control the sidechain release time independently from your audio and cv sources, giving you more control over the dynamics. CREDITS ® ENDORPHIN.ES – COCKPIT 2 / 1U Module idea, hardware design, direction and manual by Andreas Zhukovsky Programming Bsvi with extra fixes by Kouik03 Manual proofreading, beta testing and demo videos by Wisdom Water Endorphin.es are made in Barcelona, Spain Follow, like, post and tag us at Instagram: @endorphin.es COMPLIANCE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes / modifications not approved by ENDORPHIN.ES (doing business as Furth Barcelona, S.L.) could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. This device meets the requirements of the following standards: EMC: 2014/30/EU EN55032:2015; EN551032:2009 (EN55024); EN6100032; EN6100033 Low Voltage: 2014/35/EU EN 60065:2002+A1:2006+A11:2008+A2:2010+A12:2011 RoHS2: 2011/65/EU WEEE: 2012/19/EU ...
