VelociRAX Rack'em Fast Assembly And Instruction Manual page 5

●
Wrench
●
or socket
●
●
●
●
Latest instructions and videos:
1.
Insert Hinge Assembly into Hitch and Lock in Place
Insert
2.
Install Vertical Post and Tighten in Place
T R
OOLS EQUIRED
2 X 24mm
1 X 19mm
1 X 18mm
Alternate
1 X 17mm
1 X 16MM
●
1 X 13mm
A
SSEMBLY
www.velocirax.com/pages/assembly
Tip: See assembly video
www.velocirax.com/pages/assembly
3 inch washer
3.5 inch long hinge
bolt washers and nut
Not tightening to 45 ft-lbs will
increase unwanted rack motion
F A
OR SSEMBLY
2 X
I
NSTRUCTIONS
Tighten 17 mm
(25 ft-lbs / 34Nm)
Move rack while tightening
Bolt eliminates motion between receiver and rack
Tighten
24mm
(45 ft-lbs / 61 Nm)
● 6 mm
