Monicon Instruments Co., Ltd.
Copyright © 2007 Monicon Instruments Co., Ltd. All right reserved. Contents in this
publication may not be reproduced in any form without the expressed written permission of
Monicon Instruments Co., Ltd.
Precaution:
This manual contains important instructions that should be followed during
CHR-1285/2485
BATTERY CHARGER
TEL：886-4-2238-0698
FAX：886-4-2238-0891
Web
Site：http://www.monicon.com.tw
E-mail：sales@monicon.com.tw
CHR-1285/2485
Advertisement
Table of Contents
Related Manuals for Monicon Instruments CHR-1285
Summary of Contents for Monicon Instruments CHR-1285
- Page 1 TEL：886-4-2238-0698 FAX：886-4-2238-0891 Site：http://www.monicon.com.tw E-mail：sales@monicon.com.tw Copyright © 2007 Monicon Instruments Co., Ltd. All right reserved. Contents in this publication may not be reproduced in any form without the expressed written permission of Monicon Instruments Co., Ltd. Precaution: This manual contains important instructions that should be followed during...
- Page 2 Monicon Instruments Co., Ltd. CHR-1285/2485 installation and maintenance of the generator and batteries. Precaution: Read the following information carefully before attempting to install, operate or service this equipment. Also read the instructions and information on tags, decals, and labels that may be affixed to the transfer switch. Replace any decal or label that is no longer legible.
- Page 3 Monicon Instruments Co., Ltd. CHR-1285/2485 After this heading, read instructions that, if no strictly complied with, may result in personal injury or property damage. Caution After this heading, read instructions that, if not strictly complied with, could result in damage to equipment and/or property.
- Page 4 Monicon Instruments Co., Ltd. CHR-1285/2485 Never handle any kind of electrical device while standing in water, while barefoot, or while hands or feet are wet. DANGEROUS ELECTRICAL SHOCK MAY RESULT. Jewelry conducts electricity and wearing it may cause dangerous electrical shock.
-
Page 5: Table Of Contents
Short-circuit, Over load, and Over Voltage Protection prevent any damage from lead acid battery. Widely AC input voltage and adjustable DC output voltage realize the ideal of high flexibility. CHR-1285/2485 also in accordance with the principle of high Efficiency at the ratio: at Full Loaded >85% saving more energy due to the high- tech design. -
Page 6: Specifications
Monicon Instruments Co., Ltd. CHR-1285/2485 -Rugged design for industrial environments -Wide operating voltage range 3. Specifications AC Input Voltage: DC adjustable output voltage range: Voltage 80~250VAC (110/220 VAC) CHR-1285 Voltage 12-14VDC Frequency 50/60HZ CHR-2485 Voltage 25-27VDC Changing algorithm: Protection: Constant voltage then constant current... -
Page 7: Dimension
Monicon Instruments Co., Ltd. CHR-1285/2485 5.2. In charging state, because lead-acid batteries will gas, please located it on well- ventilated storage. 5.3. Avoiding the place of raining, exposing, non- neutralization or existing corrosive gas. 5.4. Battery detected voltage must over 10V(or 21V) otherwise the charger stop charging automatically. -
Page 8: Safety Precautions
Monicon Instruments Co., Ltd. CHR-1285/2485 9. Safety Precautions When operating your battery charger, basic safety precautions should always be followed to reduce the potential risk of fire, electric shock and/or injury to persons, including the following: 9.1. Read this owner’s manual thoroughly before operating your battery charger. - Page 9 Monicon Instruments Co., Ltd. CHR-1285/2485 9.3. Do not place any flammable materials such as gasoline near your battery charger. 9.4. Do not cover or obstruct ventilating opening of your battery charger. Overheating may result. 9.5. To reduce the risk of fire or electric shock, do not remove any service covers. No user’s serviceable parts are inside.
