General Operation
Turning on/off the unit
Turn on the unit by pressing any button
(except REL button (1) or
or by inserting a disc in the disc slot (18).
When system is on, press
turn off the unit.
Sound adjustment
Press VOL / button (10) to adjust the
volume level.
Press the SELECT
to cycle through the following sound
adjustment choices:
Press VOL / button (10) to
desired sound quality.
Once you are in the MENU mode, press
the SELECT button repeatedly to cycle
through the following setup choices:
Select the desired item by press
button (10) .
Loudness function
Press and hold the BAND/LOUDNESS
(8) to engage the LOUDNESS mode to
reinforce the output of bass frequencies.
Press and hold again to turn off
LOUDNESS.
Displaying/Adjusting time
1. Displaying time:
Press DISP button (15) to show current
information and time on the LCD,
to original status after 5 seconds.
2. Adjusting time:
Press and hold DISP
button (4))
button (2) to
button (9) repeatedly
adjust the
VOL /
Return
(15) until the clock
begins blinking. You can press
to adjust hour, and
minute.
Mute function
Press MUTE (3) to reduce the sound level
instantly. Press it again to return to the
previous volume level.
LCD display
Exhibits the current frequency and
activated functions on the
Flashing LED
The LED (21) will flash if the front panel is
not inserted into properly the main unit.
Reset function
The RESET button is to be activated for
the following reasons:
- Initial installation of the unit when all
wiring is completed.
- All the function buttons do not operate.
- Error symbol on the display.
RESET button (20) must be activated
with either a ballpoint pen or thin metal
object. If after pressing
the unit still does not function properly,
use a cotton swab soaked in isopropyl
alcohol to clean the socket on the back of
front panel.
SDC20 User's Manual - page 7
VOL
VOL (10) to adjust
(19).
LCD
RESET button
(10)
