0109 ALL Yardmaster International Cahore Road Draperstown BT45 7AP. www.ogrodosfera.pl Tel: 028 796 28449 Assembly Instructions Instrukcje Montażu SILVER MODEL 1010 GEYZ...
Page 2
PARTS LIST NR ELEMENTU Model Długość LISTA ELEMENTÓW PART DESCRIPTION OPIS ELEMENTU 1010 Panel ścienny 600mm 600 mm Wall Panel 101EA 1600 Panel narożny Corner Panel 103EA 1600 Panel ścienny 200mm 200mm Wall Panel 102EA 1600 Belka boczna ościeżnicy drzwi Door Post 106.29 1600...
Page 5
ASSEMBLY INSTRUCTIONS INSTRUKCJA MONTAŻU (ENGLISH) MODEL 1010. (POLSKI) MODEL 1010 Przed rozpoczęciem montażu, Before starting, read through the należy uważnie zapoznać się z assembly instructions carefully. instrukcją. Sprawdź wszystkie Check thoroughly all the parts you otrzymane części z listą części have received against the parts list (str.
Page 6
NA KAŻDĄ ŚRUBĘ NAŁOŻYĆ USZCZELKĘ Wymiary bazy Wymiary domku...
Page 7
Nałóż 401.14 na 401.2 tak aby utworzyły tylną szynę bazową KRAWĘDŹ ZEWNĘTRZNA KRAWĘDŹ ZEWNĘTRZNA Nałóż na siebie 4 otworami tak jak przedstawiono NA ZEWNĄTRZ KRAWĘDŹ ZEWNĘTRZNA...
