ASSEMBLY INSTRUCTION
ITEM NO.: 194S9525GRY-3CL
It is recommended to install protective pads under all legs and supports to avoid damage or scratches
when placing furniture on a wood floor or other hard surface, and to limit indentation and prevent discoloration
if placing on carpet.
PARTS LIST
NO.
DRAWING
1
2
3
4
5
6
HARDWARE LIST
NO.
SKETCH
A
QTY
1 PC
4 PCS
1 PC
1 PC
4 PCS
2 PCS
QTY
16 PCS
Page: 1/2
DESCRIPTION
Seat Frame
Metal Trundle Leg
LSF ARM
RSF ARM
Plastic Leg
LSF/RSF Back Cushion
DESCRIPTION
Screw
