POWER LSF RECLINING CHAIR
NOTE:
Do not use power tools for assembly. Power tools increase the risk of over tightening which
leads to splitting or cracking the wood.
COMPONENT LIST (CHAIR)
NO.
A
HARDWARE LIST
NO.
2
3
Assembly Instruction
ITEM NO.: 194S8318-LRPW
DRA \VING
DRAWING
1
1
ITEM NO.: 194S8318-3PW
QTY
DESCRIPTION
LSF BACK REST
LSF SEAT
QTY
DESCRIPTION
ADAPTOR
1
PLUG WITH WIRE
1
1
Y-CABLE
