- Page 1 CX220C Series 2 CX240C Hydraulic Excavator Service Manual Part Number 48024959 Edition English 11/2016...
- Page 2 SERVICE MANUAL CX220C SERIES 2 Standard model, TIER 3 level engine CX240C Crawler excavator-Mass excavator - TIER 3 48024959 17/11/2016...
- Page 3 Contents INTRODUCTION Engine..................10 [10.001] Engine and crankcase ............. 10.1 [10.216] Fuel tanks .
- Page 4 [39.140] Ballasts and supports ............. . 39.1 Tracks and track suspension ............
- Page 5 Thanks very much for your reading, Want to get more information, Please click here, Then get the complete manual NOTE: If there is no response to click on the link above, please download the PDF document first, and then click on it. Have any questions please write to me: admin@servicemanualperfect.com...
- Page 6 [55.408] Warning indicators, alarms, and instruments ........55.19 [55.512] Cab controls.
- Page 7 INTRODUCTION 48024959 17/11/2016...
-
Page 8: Table Of Contents
Contents INTRODUCTION Foreword - Important notice regarding equipment servicing (*) ....... . 3 Safety rules (*) . -
Page 9: Foreword - Important Notice Regarding Equipment Servicing
In any case, no warranty is given or attributed on the product manufactured or marketed by the manufacturer in case of damages caused by parts and/or components not approved by the manufacturer. -
Page 10: Safety Rules
INTRODUCTION Safety rules CX220C SERIES 2 Standard model, TIER 3 level engine CX240C Crawler excavator-Mass excavator - TIER 3 Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. -
Page 11: Safety Rules - General Information
Service parts Install CASE CONSTRUCTION genuine service parts. When placing an order, check the parts catalog. It contains the CASE CONSTRUCTION genuine part numbers. Any breakdowns arising from the installation of non-genuine parts are not covered by the warranty. Lubricants (fuel, hydraulic oil) Use the oil from the specified company or specified in the operator's manual or service Manual. -
Page 12: Safety Rules - Personal Safety
Check the operating methods in a safe location before starting the actual work. Understand the machine operations well, then operate in compliance with all service-related laws and regulations. The operator's manual can be purchased at your CASE CONSTRUCTION dealer. WARNING: Working with sloppy clothes or clothes with which safety cannot be ensured leads to damage to the machine and injury to the operator. - Page 13 INTRODUCTION WARNING: Check that there is no one in the surroundings before draining the pressure from hydraulic circuits during machine hydraulic cylinder inspection. WARNING: Use gloves when handling high-temperature parts. WARNING: Bring the lower parts or attachments in contact with the ground before inspecting or repairing them. WARNING: Check that hoses and tubes are securely connected.
-
Page 14: Safety Rules - Cab Protective Structure
INTRODUCTION Safety rules - Cab protective structure CX220C SERIES 2 Standard model, TIER 3 level engine CX240C Crawler excavator-Mass excavator - TIER 3 Cab protective structure Modifying the cab main components is prohibited in order to protect the operator. Prohibited items •... -
Page 15: Torque - Bolt And Nut
INTRODUCTION Torque - Bolt and nut CX220C SERIES 2 Standard model, TIER 3 level engine CX240C Crawler excavator-Mass excavator - TIER 3 • Tighten alternating between left and right and top and bottom so that uniform tightening force is applied. LPIL12CX00005EA •... -
Page 16: Torque - Special Torque Settings
INTRODUCTION Torque - Special torque settings CX220C SERIES 2 Standard model, TIER 3 level engine CX240C Crawler excavator-Mass excavator - TIER 3 Bolt nominal Retightening location Wrench Tightening torque Code diameter Travel motor 24 mm 267 - 312 N·m (196.93 - 230.12 lb ft) Drive sprocket 24 mm 267 - 312 N·m (196.93 - 230.12 lb ft) - Page 17 INTRODUCTION LPIL12CX00034HB 48024959 17/11/2016...
- Page 18 INTRODUCTION SMIL13CEX1312GB 48024959 17/11/2016...
- Page 19 INTRODUCTION SMIL13CEX1313GB 48024959 17/11/2016...
-
Page 20: Basic Instructions - Shop And Assembly
Only use CNH Original Parts or CASE CONSTRUCTION Original Parts. Only genuine spare parts guarantee the same quality, duration, and safety as original parts, as they are the same parts that are assembled during standard production. Only CNH Original Parts or CASE CONSTRUCTION Original Parts can offer this guarantee. - Page 21 W0111A Special tools The special tools that CASE CONSTRUCTION suggests and illustrate in this manual have been specifically re- searched and designed for use with CASE CONSTRUCTION machines. The special tools are essential for reliable repair operations. The special tools are accurately built and rigorously tested to offer efficient and long-lasting oper- ation.
-
Page 22: General Specification
INTRODUCTION General specification CX220C SERIES 2 Standard model, TIER 3 level engine CX240C Crawler excavator-Mass excavator - TIER 3 Main data Operating weight 20920 kg (46120.71 lb) Engine output 117.3 kW (159.48 Hp) / 1800 RPM Bucket capacity Heaped 0.9 m³ (31.8 ft³) Leveled 0.61 m³ (21.54 ft³) Performance Standard weight 13.5 kN (3034.921 lb)
