Case CX350C Tier 4 Service Manual
Crawler excavator
Hide thumbs
Also See for CX350C Tier 4:
- Service manual (81 pages) ,
- Service manual (22 pages) ,
- Service manual (61 pages)
Subscribe to Our Youtube Channel
Related Manuals for Case CX350C Tier 4
Summary of Contents for Case CX350C Tier 4
- Page 1 CX350C Tier 4 Crawler Excavator SERVICE MANUAL Part number 84402832 1st edition English August 2011...
- Page 2 Section 1001 Safety, general information and standard torque data 84402832 NA - May 2011...
- Page 3 84402832 NA - May 2011...
- Page 4 CONTENTS GENERAL INFORMATION................3 Safety .
- Page 5 Thanks very much for your reading, Want to get more information, Please click here, Then get the complete manual NOTE: If there is no response to click on the link above, please download the PDF document first, and then click on it. Have any questions please write to me: admin@servicemanualperfect.com...
- Page 6 84402832 NA - May 2011 Copyright © 2011 CNH FRANCE S.A. 1001-2 PRINTED IN FRANCE...
-
Page 7: General Information
When ordering refer to the Parts Catalogue for the correct part number of the genuine Case replacement items. Failures due to the use of other than genuine Case replacement parts are not covered by warranty. LUBRICATION Only use the oils and lubricants specified in the Operator’s or Service Manuals. -
Page 8: Safety
It is your responsibility to understand and follow manufacturers instructions on machine operation, ser- vice and to observe pertinent laws and regulations. Operator's and Service Manuals may be obtained from your CASE dealer. WARNING If you wear clothing that is too loose or do not use the correct safety equipment for your job, you can be injured. - Page 9 Safety, general information and standard torque data WARNING Lower all attachments to the ground or use stands to safely support the attachments before you do any maintenance or service. WARNING Pin sized and smaller streams of hydraulic oil under pressure can penetrate the skin and result in serious infection.
-
Page 10: Rops Judgment Method
Safety, general information and standard torque data ROPS Judgment Method Purpose Check against the ROPS judgment criteria to judge whether the machine satisfies the ROPS criteria or not. The weight and boom of the machine greatly effects whether the ROPS judgment criteria is satisfied or not. The ROPS test assumes that the weight being used is the weight of the machine when the maximum number of selectable options are mounted (as of 2009). - Page 11 Safety, general information and standard torque data Boom position WARNING • If the machine has been modified so that the boom position has been lowered, the machine will not satisfy the ROPS criteria. • It is necessary to consult with our company if it is possible that the boom's position has been lowered by modification.
- Page 12 Safety, general information and standard torque data Prohibited items • Modifications that reduce the strength of a platform that has a cab with a ROPS mounted to it. (Actions or modifications that reduce the functionality of the anchoring part at the left-rear of the cab) •...
- Page 13 Safety, general information and standard torque data [B series Cab] • In general, high cabs do not satisfy the ROPS criteria. (It is necessary to consult with our company to check if the high cab model satisfies the ROPS criteria.) 84402832 NA - May 2011 1001-9...
-
Page 14: Standard Torque Data For Cap Screws And Nuts
Safety, general information and standard torque data Standard Torque Data For Cap Screws And Nuts BOLT AND NUT TIGHTENING • Tighten alternating between left and right and top and bottom so that uniform tightening force is applied. • If Loctite was used on a removed bolt (there is something white sticking to the bolt when it is removed), clean the old Loctite off with cleaning fluid, dry the bolt, then apply 2 - 3 drops of Loctite to the thread section of the bolt. - Page 15 Section 1002A Specifications 84402832 NA - May 2011...
- Page 16 84402832 NA - May 2011...
-
Page 17: Table Of Contents
CONTENTS Overall (CX350C) ................. . . 3 Main Data . - Page 18 84402832 NA - May 2011 Copyright © 2011 CNH FRANCE S.A. 1002A-2 PRINTED IN FRANCE...
-
Page 19: Overall (Cx350C)
Specifications Overall (CX350C) Main Data Operating weight 34700 kg Engine output 198 kW/1900 min Performance Standard weight 18.0 kN Swing speed 9.7 min Low speed 3.2 km/h Travel speed High speed 5.4 km/h Maximum pulling force 264 kN Grade ability 70 ％... -
Page 20: Cooling System
Specifications Total stroke volume 7.790 L Maximum torque 1043 N·m/1500 min Starter 24 V 5.0 kW reduction type Charging generator 24 V 50 A AC type Battery 12 V 128 Ah/5 HR x 2 Cooling System Fan type D850 mm, 6 blades, suction Radiator Fin type Wavy... -
Page 21: Swing Units
Specifications For operating machine use Lever type (hydraulic pilot type) x 2 Instruments and switches Work mode switchover 3 modes (SP/H/A) Travel mode switchover Low-speed/high-speed switch type One-touch idle Knob switch type Engine emergency stop Switch type Monitor device Machine status display (TFT color liquid crystal) Message display Work mode select status... -
Page 22: Hydraulic Equipment
Specifications Hydraulic Equipment Hydraulic Device Hydraulic pump drive type Direct engine link (no transmission) Hydraulic pump Double variable displacement piston pump x 1 Model Gear pump x 1 Piston pump 2 x 285 L/min Discharge volume Gear pump 28.5 L/min Pump control method Simultaneous output full-horsepower control Set pressure of main relief valve... - Page 23 Section 1002B Main Equipment Table 84402832 NA - May 2011...
