Please read entire manual before starting assembly.
Keep this manual along with your purchase receipt for future reference.
WARNING:
CHOKING HAZARD-Small parts.
Not for children under 18 Months.
CAUTION
Screws contain potentially
hazardous sharp points or sharp
edges. Adult assembly required.
Contents, colors and decorations may vary from those shown.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
ASSEMBLY INSTRUCTION
OWNER'S MANUAL
WARNING:
Toy must be assembled by adult before use.
WARNING
To reduce the risk of injury, adult
supervision is required. Never use on road
ways, near motor vehicles, on or near steep
inclines or steps,swimming pools or other
bodies of water. Always wear shoes, and
never allow more than one rider.
1
IN230600323V01_UK
370-282V70
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the 370-282V70 and is the answer not in the manual?

Questions and answers

Related Manuals for HOMCOM 370-282V70

Summary of Contents for HOMCOM 370-282V70

  • Page 1 IN230600323V01_UK 370-282V70 OWNER'S MANUAL Please read entire manual before starting assembly. Keep this manual along with your purchase receipt for future reference. WARNING: WARNING: CHOKING HAZARD-Small parts. Toy must be assembled by adult before use. Not for children under 18 Months.
  • Page 2 Specifications: Battery： 6V/4.5AH*1 Motor: 6V 390# 25W*2 Suitable ages: 18+ months Maximum weight: 25kg Speed : 1.5-3km/h Power way: Charging type Charg: 12 hours ; Use: 75 hours Use of time: Charger: Input AC -240V, 50/60Hz, output DC 6V 500 mA WARNING 1.The pictures in this instruction is only for explaining the operation and structure of the product, when there's any difference with the real product, please confirm with...
  • Page 3 STORAGE BATTERY INFORMATION AND MAINTENANCE ● Please charge hours before first time use. ● Please use the suitable adapter to charge storage battery, otherwise the ride-on will be damaged. ● Please charge the car once the speed is slower than normal, otherwise it will decrease storage battery life.
  • Page 4 PREVENT FIRE AND ELECTRIC SHOCK: - Use the only rechargeable battery and charger supplied with your vehicle. - NEVER substitute the battery or the charger with another brand. Using another battery or charger may cause a fire or explosion. - Do not use the battery or charger for any other product. Overheating, fire or explosion could occur.
  • Page 5 Charge the Battery The first charge will take about 12 hours. Charge the battery directly from the socket near the seat. • Plug the battery connector into the charger port. • Plug the charger Into a standard wall outlet. The charger may feel warm during charging.
  • Page 6 PART • Please identify all parts before assembly and save all packaging material until assembly is completed to ensure that no parts are discarded. • Metal parts have been coated with lubricant for protection during shipment. Wipe all metal parts with a paper towel to remove any excess lubricant. Charger Main body Front component...
  • Page 7 Assembly Rear window Assembly: Lazyback Assembly: Insert the lazyback to the rear window as Place the rear window to the right place and fasten it with two screws(4 x 16mm) picture shown. as picture shown. Battery connection: Front components Assembly: Open the seat and you can see the power Plug connectors and put the front cable.
  • Page 8 “Snap” the seat into the right place and fasten it with two screws(4 x 16mm) as picture shown.

  • Page 9: Operating Your Vehicle

    Operating your vehicle Power switch Switch button ON and OFF. Forward Push the shifter in upward position and press the accelerator slowly. Reverse Push the shifter in downward position and press the accelerator slowly. Low speed Vehicle has been pre-set to operate at low speed (1.5 km/h) maximum.

  • Page 10: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Circuit breaker tripped Circuit breaker may "trip" and stop the vehicle if it is overloaded or the driving conditions too severe. The breaker will automatically reset after approximately 10 seconds, and the vehicle will operate normally.
  • Page 11 Problem Possible Cause Solution Check all wires and connectors. Make sure that the motor harness connector Loose wire or connectors is plugged into the battery tightly, and that there are no loose wires around the motor. Circuit breaker may "trip" and stop the vehicle if it is overloaded or the driving Car was conditions too severe.
  • Page 12 Problem Possible Cause Solution A new battery should have been charged for at least 12hours before using the vehicle for the first time. After that, it must Undercharged be recharge the battery for at least 8-10 battery hours after each use. Never charge longer than 24 hours.

  • Page 13: Parts Diagram

    Parts diagram Note: Some parts shown are assembled to both sides of the vehicle. No. Part Quantity No. Part Quantity 1. Front components 9. Rear Window 2. Main Body 10. Lazyback 3. Omni-directional wheel 11. Seat 4. Bottom fender 5. Bumper bar 6.
  • Page 14 370-282V70 Model identifie AC 100-240 Input voltage Input AC frequency 50/60 Output voltage DC 6 Output current Output power Average active efficiency 79.2 Efficiency at low load (10 %) 61.4 No-load power consumption 0.07 If you have any questions, please contact our customer care center.
