HOMCOM 833-737V80 Manual page 8

x46
A
Ø8x30mm
+2(spare)
x26
B
Ø4x40mm
+1(spare)
x48
C
Ø6x35mm
+2(spare)
x48
D
Ø15x10mm
+2(spare)
x36
E
Ø3x12mm
+2(spare)
x4
F
x5
G
x5
H
Ø4x45mm
x7
I
x1
J
x1
K
x6
L
x42
M
Ø3x14mm
+2(spare)
x14
N
x2
O
x2
P
Q x2
M6x30mm
x4
R
Ø3x16mm
x48
S
Ø20mm
x14
T
Ø4*18mm
x32
U
Ø4x14mm
+1(spare)
x4
V
Ø4x12mm
x3
CL
L300mm
x3
CR
L300mm
x3
DL
L300mm
x3
DR
L300mm
