- Page 1 INcgc065V01_GL 833-954_833-954V80 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY & INSTRUCTION MANUAL...
- Page 3 +1 (spare) M8*30 +1 (spare) +1 (spare) M4*45 +1 (spare) +1 (spare) +1 (spare)
- Page 7 OPTION #1 OPTION #2 OPTION #3 DRYWALL DRYWALL CONCRETE WALL WOOD STUD SCREW SCREW WALL ANCHOR ONLY ONLY WITH SCREW Dia:6mm Dia:6mm Option#1: Securing to Drywall. 1. Screw 4 plastic anchors(E)into drywall 2. Insert 4 screws(D)through holes on inside of cabinet and into plastic anchors(E) Option#2: Securing to Concrete wall.
- Page 8 Opción#1: Fijar al panel de yeso. 1. Atornille los 4 anclajes de plástico (E) en el panel de yeso. 2. Inserte los 4 tornillos (D) en los orificios ubicados en el interior del gabinete para que se fijen en los anclajes de plástico (E). Opción#2: Fijar a la pared de hormigón.
