- Page 1 ASCENT ™ Instruction Manual • Manuel d’utilisation Model: RVOF1200 Ascent SPx RTF...
-
Page 2: Safety Precautions And Warnings
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit www.horizonhobby.com and click on the support tab for this product. Meaning of Special Language: The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury. -
Page 3: Specifications
Included in the Box To register your product online, go to www.horizonhobby.com Transmitter AA Alkaline Ascent SPx 850 mAh 7.4V USB Charger Batteries (4) Li-Ion Battery Specifi cations Prefl ight Checklist 739mm Find a safe and open area. Charge fl ight battery. -
Page 4: Transmitter Batteries Installation
Transmitter A: Throttle B: Throttle Trim C: Rudder Trim D: Handle E: Antenna F: Speaker G: Dual Rate Switch H: LED I: Elevator/Rudder J: Aileron Trim* K: Elevator Trim L: Power Switch Transmitter Batteries Installation Remove the battery cover, install the four included AA batteries (noting proper polarity) and reinstall the battery cover. -
Page 5: Charging Warnings
Charging Warnings The USB charger has been designed to safely • Always charge batteries away from fl ammable charge the included Li-Ion battery. materials. • Always inspect the battery before charging. CAUTION: All instructions and warnings must • Always disconnect the battery after charging, and be followed exactly. -
Page 6: Wing Installation
Wing Installation 1. Carefully slide the wing into the fuselage as shown. 2. Continue sliding until the wing locks into place. 3. The wing can be removed for storage by simply pulling it back out. Tip: Firmly grasp the wing at the root (close to the center) and not out at the tips. -
Page 7: Control Test
Control Test 1. Turn the aircraft and transmitter on. 4. Note the corresponding fl ight direction to control surface movement. 2. Arm the aircraft. 5. If surfaces do not move as expected, DO NOT fl y. 3. Move the sticks on the transmitter to ensure the See the troubleshooting section in the back of aircraft responds as shown. -
Page 8: Control Centering
Control Centering After assembly, confi rm that the control surfaces are centered. If the control surfaces are not centered, mechanically center the control surfaces by adjusting the linkages. If adjustment is required, turn the clevis on the linkage to change the length of the linkage between the servo arm and the control horn. - Page 9 Flying Taking Off Get help to hand launch your aircraft so you can concentrate on fl ying. If you must hand launch the aircraft alone, hold the model in your dominant hand and the transmitter in your other hand. 1. Face into the wind and apply full (100%) throttle. 2.
- Page 10 In Flight Trim Direction of Drift Button to Correct If the aircraft’s nose drifts left, right, up or down while the sticks are at neutral (centered) press the trim buttons as shown in the chart to correct the drift. If the aircraft nose still drifts after all trim has been used, land and manually trim the aircraft.
-
Page 11: Post Flight Checklist
Post fl ight Checklist Lower throttle to 0% After charging is complete, remove the battery and store in a safe place Disconnect and remove the fl ight battery Inspect airframe and make any repairs Power off the transmitter Store in the original product box Fully charge the fl ight battery NOTICE: When you are fi nished fl ying, never... - Page 12 Tail Replacement 1. Disconnect the elevator linkage. 2. Remove one screw from the bottom of the aircraft and slide the horizontal tail out of the rear of the fuselage. 3. Slide the new tail into position and secure it with one screw.
-
Page 13: Troubleshooting Guide
Troubleshooting Guide Possible Cause Solution Problem Aircraft does not No connection Follow Binding Instructions. Follow respond to the “Installing the Flight Battery” instructions. transmitter Replace or recharge batteries Transmitter too near the aircraft or both Move to another location, with the trans- are too near large metal objects, wireless mitter more than 24 inches (60 cm) from sources or another transmitter during... -
Page 14: Limited Warranty
Limited Warranty What this Warranty Covers the event that you may need any assistance. For questions Horizon Hobby, LLC, (Horizon) warrants to the original or assistance, please visit our website at www.horizonhobby. purchaser that the product purchased (the “Product”) will be com, submit a Product Support Inquiry, or call the toll free free from defects in materials and workmanship at the date telephone number referenced in the Warranty and Service... -
Page 15: Warranty And Service Contact Information
Warranty and Service Contact Information Country of Purchase Horizon Hobby Phone Number/Email Address Address Horizon Service Center servicecenter.horizonhobby. (Repairs and Repair Requests) com/RequestForm/ productsupport@horizon- 4105 Fieldstone Rd Horizon Product Support United States of hobby.com Champaign, Illinois, 61822 (Product Technical Assistance) America 877-504-0233 websales@horizonhobby.com... -
Page 16: Compliance Information For The European Union
Compliance Information for the European Union EU Compliance Statement: Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the RED Directive. A copy of the EU Declaration of Conformity is available online at: http://www.horizonhobby.com/ content/support-render-compliance. - Page 17 CHARGEUR USB 2 CELLULES LI-ION : ASPX RVOF1209 RECEIVER/ESC: ASCENT SPX RÉCEPTEUR/VARIATEUR ESC : ASCENT SPX RVOF1210 5-WIRE 9G SERVO: ASCENT SPX 5 FILS 9G SERVO : ASCENT SPX RVOF1211 TRANSMITTER: ASCENT SPX ÉMETTEUR : ASCENT SPX Optional Parts • Pièces en option Part # • Nummer...
- Page 18 RVOF1200 © 2017 Horizon Hobby, LLC. Revolution, the Revolution logo, and Ascent are trademarks or registered trademarks of Horizon Hobby, LLC. Updated 10/17 55179.1...
