Dear Customer,
Read these instructions carefully and completely before you install the
machine. The installation should be carried out by a qualifi ed person who
is familiar with all local codes and ordinances for electrical and plumbing
connections. See also the general Safety Instructions in the Use & Care
Guide.
Cosmetic damage must be reported to the ASKO dealer within fi ve
days from the date of purchase. As soon as you unpack the machine,
thoroughly check it for cosmetic damage.
Installation instructions for condenser tumble dryer
DOMESTIC
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Asko T208VW
Summary of Contents for Asko T208VW
- Page 1 See also the general Safety Instructions in the Use & Care Guide. Cosmetic damage must be reported to the ASKO dealer within fi ve days from the date of purchase. As soon as you unpack the machine, thoroughly check it for cosmetic damage.
- Page 2 The tumble dryer can be placed on top of an To reduce the risk of of severe injury or death, ASKO washing machine. Use the two foot cups follow all installation instructions. found in the document bag included with the...
- Page 3 Installation instructions 3. Secure the anti-tip device using the screws 6. Push the tumble dryer in under the metal as shown in the picture. brackets. At the same time keep the front edge raised by 7/16" (10mm) to 7/8" (20mm) . 4.
- Page 4 ASKO dryers can be installed beneath a cabinet or worktop with a minimum height of 34” (864 mm). There must be a gap of about 1/2” (12 mm) all around the machine and a minimum gap of 1"...
- Page 5 Installation instructions Install in a closet Condensed water ASKO's front panel controls make it possible Install the dryer so the condensed water will to install the washers and dryers in a closet. continuously fl ow into a drain or sink. To do this, Make sure there is a ½”...
- Page 6 Electric models of the dryer are manufactured the washing machine or an equivalent. for a 3-wire connection system. The dryer frame ASKO washers rated 208–240 V have two is grounded by a link to the neutral conductor internal fuses of 15 A each.
- Page 7 Installation instructions Connecting a 3-wire Power Cord 5. Connect ground (center) wire of power supply cord to the center, silver-colored WARNING! terminal screw. Tighten screw. 6. Connect the other wires to outer screws. Before starting this procedure, be sure the 7.
- Page 8 Installation instructions Power Supply Cord You will need a 4-wire power supply cord with four No. 10 copper wires and a matching 4-wire receptacle of NEMA Type 14-30R, as illustrated below. The fourth wire must be identifi ed with a white cover and the ground conductor by a green cover.
- Page 9 Customer Care Center 1-800-898-1879 www.askona.com...
- Page 10 Customer Care Center 1-800-898-1879 www.askona.com...
- Page 11 Customer Care Center 1-800-898-1879 www.askona.com...
- Page 12 www.askona.com We reserve the right to make changes. TD70.1C SPK en (05-16)
