INSTALLATION AND CONNECTION
After installation, wait for 24 hours without moving
the appliance before using it for the fi rst time. If the
dryer has to be laid down on one of the sides during
transport or servicing, place it with its left side, viewing
from the appliance front, downwards.
90°
90°
DRYER PLACEMENT
The dryer can be either free standing or installed on
top of a washing machine.
The dryer emits heat. Therefore, do not place it in
a very small room, as the drying process may be
longer due to limited amount of ambient air.
Do not place the dryer in a room where
temperature can drop below 0 °C, as the machine
may not operate correctly at such low temperatures,
or freeze, which in turn can result in damage to the
machine.
For optimum dryer operation, install it in a room with
adequate ventilation and a temperature between
10 °C and 25 °C.
Do not place the dryer behind lockable or sliding
door, or door with a hinge on the opposite side of the
dryer door hinge. Install the dryer in such way that
the door can always be freely opened.
Never block the air vents.
At least two persons are required to install the
tumble dryer on top of a washing machine.
Do not place the dryer on a carpet with long
fi bres as this may impede air circulation.
8
90°
90°
Customer Care Center, 1-800-898-1879, www.askousa.com
Free-standing appliance
The dryer may be placed adjacent to a washing
machine.
If the friction between the dryer feet and the fl oor is
not suffi cient, the dryer may move during operation.
To prevent sliding, use a non-slide mat or install the
supplied vacuum feet onto both front feet.
Place the dryer so that it is stable. Use a spirit
level to level the dryer in longitudinal and traverse
direction by rotating the adjustable feet using a No.
22 spanner (max. 15 mm). Then, fi rmly tighten the
jam nuts (counter nuts) by rotating them towards the
appliance bottom using a No. 17 spanner
.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Classic T208H and is the answer not in the manual?

Questions and answers

Summary of Contents for Asko Classic T208H

  • Page 1 INSTALLATION AND CONNECTION After installation, wait for 24 hours without moving Free-standing appliance the appliance before using it for the fi rst time. If the The dryer may be placed adjacent to a washing dryer has to be laid down on one of the sides during machine.
  • Page 2 (A+B), supplied in the cardboard box in the dryer drum. Tipping guard part B is designed to fi t on ASKO 100 mm washing machines and it may be hard or impossible to mount on appliances of other brands.
  • Page 3 How to stack a dryer onto the washing machine (ASKO): There is a cardboard box in the dryer drum, containing the vacuum feet and the tipping guard. The tipping guard consists of two metal parts (A + Use two screws to attach the A part to the back of the dryer.
  • Page 4: Changing The Door Opening Direction

    CHANGING THE DOOR OPENING DIRECTION To change the direction of door opening, proceed as follows. Open the door fully. Undo the screws and remove the door. Use the screwdriver to remove the door lock cover and undo the screw on the door lock. Push the door lock upwards and remove it.
  • Page 5 Undo the door hinge assembly (left) and the door latch assembly (right), switch their positions, and replace the screws (door hinge assembly to the right- hand side, door latch assembly to the left-hand side). Use the screwdriver to remove the plastic part more easily.
  • Page 6: Draining The Condensate

    DRAINING THE CONDENSATE The moisture from the laundry is extracted in the condenser unit and accumulated in the condensate tank. Condensate tank has to be emptied regularly (see chapter "CLEANING AND MAINTENANCE"). To simplifi ed and avoid emptying and interruption of the drying cycle due to full condensate tank, run the condensate discharge tube located at the back of the appliance directly into a drain.
  • Page 7: Connecting To The Power Mains

    The dryer shall not be connected to the power The receptacle on the rear of the machine is mains using an extension cord. designed to accommodate ASKO washers ONLY (rated 208–240 V.) To use this receptacle, you must use the readyfi tted plug supplied with the washing Do not connect the tumble dryer to an electrical machine or anequivalent.
