Hartman 68174147 Assembly Instructions Manual

PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
ATTENTION:
1. Please read these instructions carefully before assembly
2. Aluminium is a soft metal and over tightening may strip thread or break the part
3. DO NOT use power tools
4. Please allow 30 minutes for assembly
5. Although assembly only requires 1 person it is advised that a second person be present to help turn the table over and into position when
fully assembled
ASSEMBLY STEPS:
1. LOOSELY attach legs (B) to table top (A) with bolts (E) and big flat washers (F) using Allen key (H) DO NOT TIGHTEN THE BOLTS AT
THIS STAGE
2. LOOSELY attach connecting bar (C) to assembled legs with bolts (E) and big flat washers (F) using Allen key (H) DO NOT TIGHTEN
THE BOLTS AT THIS STAGE
3. Tighten all bolts using Allen key one by one being careful not to over tighten any as this will cause the thread to become damaged
4. Place Nut Caps (G) on all visible bolts (E)
5. Turn table top over and place in desired position, be careful to put glass (D) on table top
For more information regarding maintenance of your furniture please visit
https://www.hartmanuk.com/home
Component's
Parts List Parts Picture
A
B
C
D
For replacement or lost spare parts please go to
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
ASSEMBLY INSTRUCTIONS
Westbury 150x80cm Rectangular Table
( 68174147 / 68182146
Description Q'ty Part no
68174147A
Table Top 1 68182146A
68174147B
Legs 2 68182146B
68174147C
Connecting 1 68182146C
bar
68174147D
Glass 68182146D
http://spares.hartmanuk.co.uk/purchase
)
Fixings
Parts list Parts Picture
E
F
G
H
Description Q'ty Part no.
M6*25 bolt 8 1231162
Flat washer 8 1061162
2100036
PVC cap 8 2100037
2002191
Allen key 1
