Electrical Connector; Outline Drawing - PCB Piezotronics ICP YJM320C15 Installation And Operating Manual

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
.312 [7.92] HEX
.33 [8.3]
.21 [5.4]
3 .10 [2.5]
 .275 [
A
3 STUD REMOVED FOR SENSOR WITH ADHESIVE MOUNT OPTION
2 M3 x 0.50-6g FOR SENSOR WITH METRIC OPTION
1 ADD CABLE FOR SENSOR WITH WATER RESISTANT OPTION
4
3

ELECTRICAL CONNECTOR

5-44 UNF - 2A
5-40 UNC - 2A 2
 6.99]
3
2
INTEGRAL SEALED CABLE 1
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DRAWN
DIMENSIONS IN INCHES DIMENSIONS IN MILLIMETERS
JJF
[ IN BRACKETS ]
DECIMALS XX ±.03 DECIMALS X ± 0.8
XXX ±.010 XX ± 0.25
TITLE
ANGLES  2 DEGREES ANGLES  2 DEGREES
CABLE TOLERANCES IN ENGLISH CABLE TOLERANCES IN METRIC
1"≤ LENGTH < 1' = +1"/ - 0
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
30.5cm ≤ LENGTH < 1.5m = +5.1cm/ - 0
5'≤ LENGTH < 100' = +6"/ - 0
1.5m ≤ LENGTH < 30.5m = +15.2cm/ - 0
30.5m ≤ LENGTH = +30.5cm/ - 0
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII FILLETS AND RADII
.003 - .005 0.07 - 0.13
2
1
REVISIONS
REV DESCRIPTION
A .312 [7.92] WAS .312 [7.93]
CHECKED ENGINEER
2/27/23 JJF 2/27/23 BAM 2/27/23
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com

OUTLINE DRAWING

DWG. NO.
320C15 SERIES CODE
10055
IDENT. NO.
ACCELEROMETER
52681
SCALE: 6X
1
DIN
53651
B
A
SHEET 1 OF 1
