PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
.695 [17.65]
.10 [2.5]
A
1
M3x.5-6g FOR SENSOR WITH METRIC OPTION
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS
XX ±.03
XXX ±.010
ANGLES
2 DEGREES
CABLE TOLERANCES IN ENGLISH
1"≤ LENGTH < 1'
=
+1"/ - 0
1'≤ LENGTH < 5'
=
+2"/ - 0
5'≤ LENGTH < 100'
=
+6"/ - 0
100'≤ LENGTH
=
+1'/ - 0
FILLETS AND RADII
.003 - .005
2
DIMENSIONS IN MILLIMETERS
NJF
[ IN BRACKETS ]
DECIMALS
X ± 0.8
XX ± 0.25
TITLE
ANGLES
2 DEGREES
CABLE TOLERANCES IN METRIC
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
30.5cm ≤ LENGTH < 1.5m
= +5.1cm/ - 0
1.5m
≤ LENGTH < 30.5m
= +15.2cm/ - 0
30.5m ≤ LENGTH
= +30.5cm/ - 0
FILLETS AND RADII
0.07 - 0.13
2
REV
B
UPDATED TITLE BLOCK, ADDED NOTE
2X
.360 [9.14]
DRAWN
CHECKED
08/12/22
08/12/22
JDM
OUTLINE DRAWING
621C40 SERIES
ACCELEROMETER
1
REVISIONS
DESCRIPTION
ELECTRICAL CONNECTOR
5-44 UNS - 2A
3/8 [10] HEX
5-40 UNC - 2A
ENGINEER
08/12/22
GGS
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE:
6X
1
DIN
53107
B
1
A
10108
SHEET
1 OF 1
