HOMCOM 370-276V00 Assembly Instruction Manual page 4

2. Attach the Rear Wheels
4
2
5
6
1
3
1. Slide the drive bracket into the rear axle.
2-3.attach the drive bracket to the rear axle using M5*25 screws and M5 nuts.
4. Slide the rear wheel into the rear axle so that it is connected to the drive bracket.
5. Slide a 10 washer onto the rear axle.
6. Tighten the lock M10 nut to the end of the rear axle using a wrench.
7. Slide the rear wheel into the rear axle .
8. Slide a 10 washer onto the rear axle.
9. Tighten the lock M10 nut to the end of the rear axle using a wrench.
