Hose Reel
Art.no 31-4717
Please read the entire instruction manual before using the product and save it for future reference.
We reserve the right for any errors in text or images and any necessary changes made to
technical data. If you have any questions regarding technical problems please contact
Customer Services.

Safety

Warning!
This hose reel is not a toy; do not let children play with it.

Product description

Portable hose reel which also has a wall bracket. Comes with hose pipe, couplings and spray
nozzle. Includes 25 metres of braided ½-inch diameter hose and 2 metres of connection hose.
Assembly
Hold the bracket up against a wall and mark out the position for the holes with a pencil.
Mount the bracket onto the wall using the provided screws and wall plugs.

Useful Tips

The hose must not be under pressure when it is rewound onto the reel.
Close the water inlet and leave the nozzle open before rewinding the hose.

Disposal

Follow local ordinances when disposing of this product.
If you are unsure how to proceed, contact your local authority.

Specifications

Hose
25 m (PVC), Ø ½" (12 mm)
Max pressure
6 bar (600 kPa)
Coupling thread
¾" and ½" NPT
Size
28 × 38 × 44 cm
GREAT BRITAIN • CUSTOMER SERVICE
tel. 08545 300 9799 web: www.clasohlson.co.uk
e-mail: customerservice@clasohlson.co.uk
Model
HL-W-30
