Hose Reel Cart
Art.no 31-4716
Please read the entire instruction manual before using the product and save it
for future reference. We reserve the right for any errors in text or images and
any necessary changes made to technical data. If you have any questions
regarding technical problems please contact Customer Services.
Safety
Warning!
This hose reel is not a toy; do not let children play with it.
Product description
Complete cart set consisting of hose, couplings and hose nozzle. Includes
45 metres of braided ½-inch diameter hose and 2 metres of connection hose.
Assembly
1
2
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk
and click on customer service.
Model HL-02
To wheels
To upper part
4
5
Use
The hose must not be under pressure when it is rewound onto the reel.
Close the water inlet and leave the nozzle open before rewinding the hose.
Disposal
Follow local ordinances when disposing of this product.
If you are unsure how to proceed, contact your local authority.
Specifications
Hose
45 m (PVC), Ø ½" (12 mm)
Max pressure
6 bar (600 kPa)
Coupling thread ¾" and ½" NPT
Size (l x w x h)
47 x 43 x 114 cm
3
6
