3-206-417-12 (1)

Printer Driver

Installation Guide
This guide describes installation and use of the Printer
Drivers for Windows 2000, Windows Me, Windows 98, and
Macintosh.
Before Using this Software
Before using the printer driver, be sure to read the "ReadMe"
file located in the same folder of the printer driver on the
CD-ROM.
DPP-MP1
© 2001 Sony Corporation

Advertisement

Table of Contents
loading

Related Manuals for Sony DPP-MP1

Summary of Contents for Sony DPP-MP1

  • Page 1: Printer Driver

    Drivers for Windows 2000, Windows Me, Windows 98, and Macintosh. Before Using this Software Before using the printer driver, be sure to read the “ReadMe” file located in the same folder of the printer driver on the CD-ROM. DPP-MP1 © 2001 Sony Corporation...

  • Page 2: Table Of Contents

    Macintosh Printer Driver Installing the Printer Driver ...23 Removing the Printer Driver ...23 Making Printer Settings ...24 Select the DPP-MP1 with the Chooser ...24 Selecting the Paper Type ...24 Making Print Settings ...25 Windows 2000 Microsoft and Windows are registered trademarks of Microsoft Corporation.

  • Page 3: Windows 2000 Printer Driver

    Windows 2000 Printer Driver DPP-MP1...

  • Page 4: Installing The Printer Driver

    Installing the Printer Driver Connect the DPP-MP1 to the computer. Switch the DPP-MP1 on. Switch on the computer, and then log in as the system administrator. After Windows 2000 starts up, the [Found New Hardware Wizard] opens. If the [Found New Hardware Wizard] does not...

  • Page 5: Removing The Printer Driver

    On the [File] menu, click [Delete]. The printer driver removal is complete. To delete the INF file Delete the DPP-MP1 INF file located in C://WinNT/Inf. Note Depending on your Windows settings, the “Inf” folder may not be displayed. To display the folder, open [My Computer] and click [Folder Options] on the [Tools] menu.

  • Page 6: Using The Printer Driver

    You can use the printer driver [Printing Preferences] to set the default settings for the paper size, orientation, and other important settings. Open the [Printers] folder in the [Control Panel], right-click the [Sony DPP-MP1] icon, and then select [Printing Preferences]. The [Sony DPP-MP1 Printing Preferences] sheet opens and presents the following tabs and items for setting.

  • Page 7: [Graphics] Tab

    You an adjust the sharpness of the image outline by dragging the slider to the left or right, entering a value directly into the box, or clicking the arrows next to the box to increase or decrease the setting. Using the Printer Driver...
  • Page 8 [Color Correction] Select the color correction method. • Select [Printer Hardware Color Correction] to have the printer correct the color automatically. • Select [ICM Color Correction] to use a color profile for color correction. Windows 2000 Using the Printer Driver...

  • Page 9: Windows Me Printer Driver

    Windows Me Printer Driver DPP-MP1...

  • Page 10: Installing The Printer Driver

    Installing the Printer Driver Connect the DPP-MP1 to the computer. Switch the DPP-MP1 on. Switch on the computer. After Windows Me starts, the [Add New Hardware Wizard] opens. If the [Add New Hardware Wizard] does not open, double-click the [My Computer] icon. Then...

  • Page 11: Removing The Printer Driver

    The printer driver removal is complete. To remove the Sony USB driver Note • Exit all programs before you remove the Sony USB driver. • Before removing the Sony USB driver, make sure that all Sony printer drivers that use the USB port have been removed.

  • Page 12: Using The Printer Driver

    Click the [OK] button. When the removal procedure finishes, the following dialog box opens. Note If another printer is using the Sony USB driver, the following dialog box appears. Click the [OK] button. This stops the removal procedure. Click the [OK] button.

  • Page 13: [Graphics] Tab

    [Brightness], [Contrast] and [Saturation] settings to adjust the image. • Select [Auto] to achieve the best possible processing for a digital image. • Select [Custom] to manually adjust the [Brightness], [Contrast], and [Saturation] of the image. Using the Printer Driver...
  • Page 14 Windows Me [Color Correction] Select the color correction method. • Select [Printer Hardware Color Correction] to have the printer correct the color automatically. • Select [ICM Color Correction] to use a color profile for color correction.

  • Page 15: Windows 98 Printer Driver

    Windows 98 Printer Driver DPP-MP1...

  • Page 16: Installing The Printer Driver

    Installing the Printer Driver Connect the DPP-MP1 to the computer. Switch the DPP-MP1 on. Switch on the computer. After Windows 98 starts, the [Add New Hardware Wizard] opens. If the [Add New Hardware Wizard] does not open, double-click the [My Computer] icon. Then...
  • Page 17 If the [Add New Hardware Wizard] does not open, double-click the [My Computer] icon. Then double-click the [Control Panel] folder, double- click the [Printers] folder, and double-click [Add Printer]. Follow the instructions displayed to install the printer driver. Click the [Next] button. The next screen opens.

  • Page 18: Removing The Printer Driver

    The printer driver removal is complete. To remove the Sony USB driver Note • Exit all programs before you remove the Sony USB driver. • Before removing the Sony USB driver, make sure that all Sony printer drivers that use the USB port have been removed.

  • Page 19: Using The Printer Driver

    Click the [OK] button. When the removal procedure finishes, the following dialog box opens. Note If another printer is using the Sony USB driver, the following dialog box appears. Click the [OK] button. This stops the removal procedure. Click the [OK] button.

  • Page 20: [Graphics] Tab

    • [Texture] The image is printed with a silk screen finish. • [Matte] The image is printed with a matte finish. [About] Click to display the number of the installed printer driver and other information. [Restore Defaults] Restores the default selections for these settings.
  • Page 21 Windows 98 [Color Correction] Select the color correction method. • Select [Printer Hardware Color Correction] to have the printer correct the color automatically. • Select [ICM Color Correction] to use a color profile for color correction.

  • Page 22: Macintosh Printer Driver

    Macintosh Printer Driver DPP-MP1 © 2001 Sony Corporation...

  • Page 23: Installing The Printer Driver

    Follow the instructions displayed on the screen. When installation is complete, restart the Macintosh. Note • When using the DPP-MP1 and the UP-DP10 at the same time, install the printer driver for the UP-D10 first, and then install the printer driver for the DPP-MP1.

  • Page 24: Making Printer Settings

    Making Printer Settings Select the DPP-MP1 with the Chooser Select the DPP-MP1 with the Chooser it use it for the first time, or whenever you want to use it after using another printer. First, make sure that the DPP-MP1 is properly connected to the Macintosh with the USB cable, and that the DPP-MP1 is on.

  • Page 25: Making Print Settings

    [Digital Camera…] When printing an image captured with a digital camera, you can use the [Brightness], [Contrast], and [Saturation] settings to adjust the image. • Select [Auto] to achieve the best possible processing for a digital image. Making Printer Settings Macintosh...
  • Page 26 When “Use ColorSync” is selected, you can select the following options. • In the [Profile] pull-down list, you can specify the DPP-MP1 profile. • In the [Intent] pull-down list, you can select any of the following color reproduction mapping. Perceptual (Images)
