Summary of Contents for Daewoo DATS255
- Page 1 DATS255 TABLE SAW USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1.SAFETY REGULATIONS........................... 1 2.LAYOUT AND ITEM SUPPLIED........................ 2 3.PROPER USE ............................3 4.TECHNICAL DATA............................ 4 5.BEFORE STARTING THE EQUIPMENT....................5 6.ASSEMBLY..............................5 7.USING THE SAW............................5 8.OPERATION.............................. 5 9.REPLACING THE CABLE POWER......................5 10.CLEANING, MAINTENANCE AND ORDERING OF SPARE PARTS............. 5 11.DISPOSAL AND RECYCLING........................ -
Page 3: Safety Regulations
1. SAFETY REGULATIONS Caution! Wear ear-muffs. The impact of noise can cause damage to hearing. Caution! Wear a breathing mask. Dust which is injurious to health can be generated when working on wood and other materials. Never use the device to work on any materials contai ning asbestos! Caution! Wear a breathing mask. - Page 4 –Do not expose electric tools to rain –Do not use electric tools in a damp or wet envi-ronment. – Make sure that the work area is well-illuminated. –Do not use electric tools where there is a risk of fire or explosion. 3.
- Page 5 –During non-use of the electric tool or prior to maintenance and when replacing tools such as saw blades, bits, milling heads. –When the saw blade is blocked due to abnormal feed force during cutting, turn the machine off and disconnect it from power supply. Remove the work piece and ensure that the saw blade runs free. Turn the machine on and start new cutting operation with reduced feed force.
- Page 6 –Wear goggles. Sparks generated during work or splinters, chippings and dust coming from the device can lead to loss of eyesight. –Connect a dust collecting device to the electric tool when sawing wood. The emission of dust is influe ced, among other things, by the type of material to be processed, the significance of local separation (collection or source) and the correct setting of the hood/guide plates/guides.
-
Page 7: Layout And Item Supplied
SAFETY INSTRUCTIONS FOR THE HANDLING OF SAW BLADES 1 Only use insertion tools if you have mastered their use. 2 Observe the maximum speed. The maximum speed specified on the insertion tool may not be excee- ded. If specified, observe the speed range. 3 Observe the motor / saw blade direction of rota-tion. -
Page 8: Proper Use
30 Cross strut 31 Longitudinal strut 32 Supports 33 Table width extension 34 Tool hook A Additional leg a Hex screw b Spring washer c Washer d Nut 2.2 Items supplied Please check that the article is complete as specifi ed in the scope of delivery. If parts are missing, please contact our service center or the sales outlet where you made your purchase at the latest within 5 working days after purchasing the product and upon presentation of a valid bill of purchase. -
Page 9: Technical Data
To use the equipment properly you must also observe the safety information, the assembly instructions and the operating instructions to be found in this manual. To use the equipment properly you must also observe the safety information, the assembly instructions and the operating instructions to be found in this manual. All persons who use and service the equipment have to be acquainted with these operating instructions and must be informed about the equipment‘s potential hazards. -
Page 10: Before Starting The Equipment
The quoted values are emission values and not necessarily reliable workplace values. Although there is a correlation between emission and im-mission levels it is impossible to draw any certain conclu- sions as to the need for additional precau-tions. Factors with a potential infl uence on the ac-tual immis- sion level at the workplace include the duration of impact, the type of room, and other sources of noise etc., e.g. - Page 11 • Use the washers (c) and the hex screws (a) to fasten the 4 legs (29) loosely to the saw. • Now use the hex screws (a), the washers (c) and the nuts (d) to fasten the longitudinal-struts (31) and the cross-struts (30) loosely to the legs. Please note: The longer struts have to be used on the sides.
-
Page 12: Using The Saw
6.6 Assembling the table width extension (Fig. 18) • Use the screws (a), nuts (d) and washers (c) to fasten the table width extensions (33) loo-sely to the saw table (1). • Screw the supports (32) loosely onto the saw housing and onto the table width extensions (33). -
Page 13: Operation
Important! • Do not push the stop rail (23) too far toward the blade. • The distance between the stop rail (23) and the blade (4) should be approx. 2 cm. 7.5. Setting the angle (Fig. 14) • Undo the fixing handle (9). •... -
Page 14: Replacing The Cable Power
• Set the parallel stop (7) in accordance with the workpiece width and height (see 7.3.1) • Carry out the cut in accordance with the work-piece width (see 8.1.1., 8.1.2 and 8.1.3.) 8.1.5. Making cross cuts (Fig. 23) • Slide the cross stop (21) into one of the grooves (21) in the table and adjust to the required angle. (See 7.4.) If you also want to tilt the blade (4), use the groove (21) which prevents your hand and the cross stop frommaking contact with the blade guard. - Page 23 Manufactured under license of Daewoo International Corporation, Korea...
