ASSEMBLY, MAINTENANCE, &
USER MANUAL
MODEL # SJG205
WARNING
Read the assembly, installation, care, maintenance, and use
instructions in this manual prior to assembling and using this
equipment. Save this manual for future reference.
Ages: 4-8
Maximum occupancy: 1 user
Skywalker Holdings LLC
Maximum weight: 81 lbs
P.O. Box 574, Brigham City, UT 84302
Advertisement
Table of Contents
Related Manuals for skywalker sports ActivPlay SJG205
Summary of Contents for skywalker sports ActivPlay SJG205
- Page 1 ASSEMBLY, MAINTENANCE, & USER MANUAL MODEL # SJG205 WARNING Read the assembly, installation, care, maintenance, and use instructions in this manual prior to assembling and using this equipment. Save this manual for future reference. Ages: 4-8 Maximum occupancy: 1 user Skywalker Holdings LLC Maximum weight: 81 lbs P.O.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Part List.....................................3 Part Identification................................4-5 Exploded Drawing................................6 Assembly.....................................7-11 Installation.....................................12 Maintenance & Care Information..........................13 Jungle Gym Safety information..........................14 Instructions for Use...............................15 Warning Label Placement............................16 Playground Surfacing Materials Information....................17 Limited Warranty................................18 STOP EVERYTHING YOU'RE DOING AND REGISTER YOUR PRODUCT Find our warranty registration online by typing in: www.skywalkertrampolines.com/registration/ You'll need to have the following information handy: •... -
Page 3: Part List
PART LIST Key No. Qty. Description Bottom Frame 1 Bottom Frame 2 Top Frame 1 Top Frame 2 Cross Bar Upright Bars M8 Arc Washer M8x35mm Button Bolt M8X20mm Button Bolt M6 Locknut M8 Washer D50 Inner Cap Plastic Protector M6 Washer M6x40mm Button Bolt Wrench... -
Page 4: Part Identification
PART IDENTIFICATION Before you begin, take a look at the drawings below to make sure you have all the parts! The numbers in the squares to the left (key numbers) will help you identify the parts during assembly. Bottom Frame 1 Bottom Frame 2 Top Frame 1 (x1) - Page 5 M6x40mm Button Plastic M6 Washer Bolt (x18) Protector (x18) (x18) 5mm Hex Key 4mm Hex Key (x1) Wrench (x1) (x1)
-
Page 6: Exploded Drawing
EXPLODED DRAWING (12) (7) (9) (12) (9) (7) (13) (13) (13) (13) (13) (11) (13) (9) (7) (13) (11) (13) (13) (13) (13) (13) (13) (13) (13) (15) (13) (14) (13) (10) (13) -
Page 7: Assembly
ASSEMBLY READ THIS BEFORE YOU BEGIN • We’ve provided some tools to help with assembly, but you’re more than welcome to use your own • The assembly steps refer to parts by their descriptions and key numbers (see the part list on page 3) •... - Page 8 ASSEMBLY STEP 3 Now, place the bottom frame 1 (1) and bottom frame 2 (2) onto the ground as shown. Insert one end of a cross bar (5) from previous step into the bottom frame 1 (1). Insert the other end of the cross bar (5) into the bottom frame 2 (2).
- Page 9 STEP 5 Insert the male ends of the top frame 1 (3) and top frame 2 (4) into the female ends of the bottom frame 1 (1) and bottom frame 2 (2). Secure the two pieces together with the M8 arc washers (7) and the M8X20mm button bolts (9).
- Page 10 ASSEMBLY STEP 7 Remove the two plastic caps from the Jungle Gym Base. Insert the upright bars (1) into the now open poles of the Jungle Gym Base. Secure with four M8 arc washers (7), four M8 washers (11), and eight M8X20mm button bolts (9). Now Tighten all Nuts and Bolts .
- Page 11 STEP 9 We recommend anchoring this product to prevent tipping, overturning , or lifting of the support members. Anchors are not provided and will need to be purchased separately. The recommended size is shown below. To install the anchors, simply push or hammer the anchors into the ground through the holes located on the feet at the bottom of the arched ladder climber.
-
Page 12: Installation
INSTALLATION WARNING! To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on the Jungle Gym Base Station before assembly and use of this product. It is the responsibility of the owner and supervisors of this Arched Ladder Climber to make sure all users obey the safety instructions printed in this material. -
Page 13: Maintenance & Care Information
MAINTENANCE & CARE INFORMATION Congratulations and high five on successfully assembling your new ActivPlay Arched Ladder Climber! Now, the best way to keep your new Accessory in tip-top shape, is to follow this checklist periodically: At the beginning of each play season: •... -
Page 14: Jungle Gym Safety Information
JUNGLE GYM SAFETY INFORMATION A Jungle Gym is a recreational product. The information on this manual identify important safety precautions. The precautions are not all-inclusive, because a Jungle Gym can be used in ways that this manual cannot cover completely. USING THE JUNGLE GYM SAFELY Adult Supervision of Children Children using the Jungle Gym must be supervised by adults at all times. -
Page 15: Instructions For Use
INSTRUCTIONS FOR USE To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use this equipment. Warnings and instructions for care, maintenance, and use of this Jungle Gym Accessory are included to promote safe enjoyable use of this equipment. -
Page 16: Warning Label Placement
WARNING LABEL PLACEMENT The labels shown on this page have been attached to the Jungle Gym Base Station in the indicated locations. If one of the labels is missing or illegible, call our Customer Care Hotline toll-free at 1-866-603-JUMP (5867), Monday to Thursday, 8 a.m. -
Page 17: Playground Surfacing Materials Information
PLAYGROUND SURFACING MATERIALS The following information is from Section 4 of the United States Consumer Product Safety Commission’s (USCPSC) Outdoor Home Playground Safety Handbook for playground surfacing material. X3. SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION’S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK X3.1 Select Protective Surfacing —... -
Page 18: Limited Warranty
LIMITED WARRANTY Skywalker Holdings, LLC warrants its products to be free from defects in material and workmanship under normal use and service conditions. The steel frame is warranted for three (3) years after the date of purchase. All other parts are warranted for one (1) year after the date of purchase. Warranty coverage extends only to the original retail purchaser from the date of original purchase. - Page 19 NOTE: Skywalker Holdings, LLC is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenue or profits, loss of enjoyment or use, cost of removal, installation or other consequential damages.
