Assembly Installation, Care Maintenance
and User Instructions Manual
WARNING
!
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
Maximum occupancy 2 users.
Maximum weight capacity .
80 lbs
AGES 4 to 8
IMPORTANT
CHOKING HAZARD
due to small parts
Adult assembly required
Please retain for for future reference.
Two capable adults required
for all the assembly procedure.
Failure to follow this warning
could result in serious injury
and/or property damage.
STT100
Model
__________
Skywalker Holdings LLC
PO Box 574, Brigham City, UT 84302
____
Model
STT100
™
