ASSEMBLY, MAINTENANCE, &
USER MANUAL
MODEL #SJG203.1
WARNING
Read the assembly, installation, care, maintenance, and use
instructions in this manual prior to assembling and using this
equipment. Save this manual for future reference.
Ages: 4-8
Maximum occupancy: 1 user
Skywalker Holdings LLC
Maximum weight: 81lbs
P.O. Box 574, Brigham City, UT 84302
Advertisement
Table of Contents
Related Manuals for skywalker sports SJG203.1
Summary of Contents for skywalker sports SJG203.1
- Page 1 ASSEMBLY, MAINTENANCE, & USER MANUAL MODEL #SJG203.1 WARNING Read the assembly, installation, care, maintenance, and use instructions in this manual prior to assembling and using this equipment. Save this manual for future reference. Ages: 4-8 Maximum occupancy: 1 user Skywalker Holdings LLC Maximum weight: 81lbs P.O.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Part List.....................................3 Part Identification................................4-5 Exploded Drawing................................6 Assembly.....................................7-11 Installation.....................................12 Maintenance & Care Information..........................13 Jungle Gym Safety information..........................14 Instructions for Use...............................15 Warning Label Placement............................16 Playground Surfacing Materials Information....................17 Limited Warranty................................18 STOP EVERYTHING YOU'RE DOING AND REGISTER YOUR MONKEY BARS ACCESSORY Find our warranty registration online by typing in: www.skywalkertrampolines.com/registration/ You'll need to have the following information handy: •... -
Page 3: Part List
BEFORE YOU BEGIN Thanks for choosing Skywalker Sports! We’re just as excited as you are to help your family live an active (but most importantly FUN) lifestyle. This model is one of our favorites, and we’re confident you’ll love it too. To make things easier for you, we’ve listed important information that you need to know. -
Page 4: Part Identification
PART IDENTIFICATION Before you begin, take a look at the drawings below to make sure you have all the parts! The numbers in the squares to the left (key numbers) will help you identify the parts during assembly. Top Frame 1 Top Frame 2 Upright 1 (x1) - Page 5 M6x40mm Button Blue Plastic Yellow Plastic Bolt (x16) Protector (x4) Protector (x12) M6 Locknut M8X35mm Button M6 Washer (x16) Bolt (x16) (x16) 5mm Hex Key 4mm Hex Key (x1) Wrench (x1) (x1)
-
Page 6: Exploded Drawing
EXPLODED DRAWING (12) (12) (18) (10) (18) (15) (16) (18) (15) (17) (13) (18) (13) (16) (13) (18) (14) (13) (13) (18) (10) (13) (12) (15) (13) (13) (18) (16) (17) (13) (13) (18) (14) (13) (18) (13) (18) (11) (17) (14) (11) -
Page 7: Assembly
ASSEMBLY READ THIS BEFORE YOU BEGIN • We’ve provided some tools to help with assembly, but you’re more than welcome to use your own • The assembly steps refer to parts by their descriptions and key numbers (see the part list on page 3) •... - Page 8 ASSEMBLY STEP 3 Place the Top Frame 1 (1) and Top Frame 2 (2) on the ground as shown. Attach the Cross Top Bar (5) to the Top Frame 1 (1) and Top Frame 2 (2) with M8X35 mm Button Bolts (18) and M8 Arc Washers (7). Do not tighten the locknuts.
- Page 9 STEP 5 Attach the Step Cross Bar (6) to the Upright 1 (3) and Upright 2 (4) with M8X35mm Button Bolts (18) and M8 Arc Washers (7). Do not tighten the locknuts. Repeat this step until another Step Cross Top M8X35mm Upright 2 M8 Arc...
- Page 10 ASSEMBLY STEP 7 Remove the two Plastic Caps from the Jungle Gym. Attach the Top Frames (1) to the Jungle Gym with eight M8X20mm Button Bolts (9) and four M8 Arc Washers (7) and four M8 Washers (11). Tighten all the Nuts. M8X20mm M8 Arc M8 Washer...
- Page 11 STEP 9 Use the hammer to make the anchor into the ground in the direction as shown. The anchor effect is to prevent tipping, overturning , or lifting of the support members. Note: The anchor is not provided in this product and need to be purchased seperately. The recommended size of the anchor is shown below.
-
Page 12: Installation
INSTALLATION WARNING! To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on the Jungle Gym Base Station before assembly and use of this product. It is the responsibility of the owner and supervisors of this Jungle Gym Base Station to make sure all users obey the safety instructions printed in this material. -
Page 13: Maintenance & Care Information
MAINTENANCE & CARE INFORMATION Congratulations and high five on successfully assembling your new Skywalker Sports Monkey Bars Accessory! Now, the best way to keep your new Monkey Bars Accessory in tip-top shape, is to follow this checklist periodically: At the beginning of each play season: •... -
Page 14: Jungle Gym Safety Information
Jungle Gym SAFETY INFORMATION A Jungle Gym is a recreational product. The information on this manual identify important safety precautions. The precautions are not all-inclusive, because a Jungle Gym can be used in ways that this manual cannot cover completely. USING THE JUNGLE GYM SAFELY Adult Supervision of Children Children using the Jungle Gym must be supervised by adults at all times. -
Page 15: Instructions For Use
INSTRUCTIONS FOR USE To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use this equipment. Warnings and instructions for care, maintenance, and use of this Jungle Gym Monkey Bars Accessory are included to promote safe enjoyable use of this equipment. -
Page 16: Warning Label Placement
7 children P.O. Box 547 Brigham City, UT 84302 SJG200 3 children SJG201 2 children www.skywalkertrampolines.com SJG202 1 children Factory address: Qingda Industrial SJG203.1 1 children Park Chengyang Qingdao Shandong The total maximum weight not exceed of 567 lbs. China... -
Page 17: Playground Surfacing Materials Information
PLAYGROUND SURFACING MATERIALS The following information is from Section 4 of the United States Consumer Product Safety Commission’s (USCPSC) Outdoor Home Playground Safety Handbook for playground surfacing material. X3. SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION’S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK X3.1 Select Protective Surfacing —... -
Page 18: Limited Warranty
LIMITED WARRANTY Skywalker Holdings, LLC warrants its products to be free from defects in material and workmanship under normal use and service conditions. The steel frame is warranted for three (3) years after the date of purchase. All other parts are warranted for one (1) year after the date of purchase. Warranty coverage extends only to the original retail purchaser from the date of original purchase. - Page 19 NOTE: Skywalker Holdings, LLC is not responsible or liable for indirect, special or consequential damaages arising out of or in connection with the use or performance of the product or other damages with respect to any econmic loss, loss of property, loss of revenue or profits, loss of enjoyment or use, cost of removal, installation or other consequential damages.
