- Page 2 IMPORTANT READ BEFORE COMMENCING INSTALLATION ALL GEMINI UNITS MUST BE INSTALLED BY A COMPETENT PERSON. UNIT SPECIFICATIONS: CONTENTS OF PACKAGE: Feed water quality: Municipal tap water Reverse Osmosis Unit - 1 pc Tee Fitting Voltage and frequency: 100-240V, 50/60Hz Housing Wrench - 1 pc Power input: 96W Food Grade Tubing - 3 pcs (Red, White, Blue) Purified water flow: 1.2L/Min...
- Page 3 / FEED WATER VALVE AND TEE FITTING / DRAIN CLAMP INSTALLATION • Install Tee Fitting Valve shown below to your 15mm cold water pipe. Position drain clamp on drain pipe above the drain trap and tighten securely. • Attach the grey plastic adapter to the male thread on the tee fitting. Using the drain clamp as a guide, drill a 6mm hole, enough for the 1/4”...
- Page 4 / CARTRIDGES REPLACEMENT AND REMINDER / CARTRIDGE REPLACEMENT FILTER REPLACEMENT (FOR REFERENCE ONLY) 6 months 6 months 6 months Upon Exhaustion 6 months / NOTE Cartridge replacement reminder: Filters are to be replaced every 6 months. However, after working for 50 hours cumulatively, indicator light turns green and buzzer keeps ringing for 10 seconds.
- Page 5 Consumers are asked to purchase quality-guaranteed accessories through regular channels. Monarch Water is not responsible for the quality of non-original accessories because of the quality problems of the accessories purchased by consumers. Monarch Water assumes no responsibility for any water leakage accident.
- Page 6 TO ORDER SPARE PARTS Please contact your dealer for more information. + 44 (0) 1986 784759 monarchwater.co.uk info@monarchwater.co.uk...
