- Page 1 WATER CONDITIONER INSTALL GUIDE MG-1 MG-2 MG-3 MG-4...
- Page 2 The symbol opposite means that according to United Kingdom and European Union member countries laws and regulations your product and/or its battery shall be disposed of separately from household waste. When this product reaches its end of life, take it to a collection point designated by local authorities.
-
Page 3: Planning The Installation
/ MONARCH MAGNESIO WATER CONDITIONER PROGRAMMING & INSTALLATION INSTRUCTIONS Thank you for choosing our water conditioner. Please read the following carefully, which if followed correctly, should ensure the installation is trouble free. / A. PLANNING THE INSTALLATION • Always observe the water byelaws. •... -
Page 4: Installation
/ E. INTEGRATED BYPASS OPERATION OUTLET INLET METER HOLE OUTLET HANDLE INLET HANDLE UNIT IN BYPASS UNIT IN SERVICE POSITION NOT ALLOWED Ensure bypass handles are completely open when in service to ensure no unconditioned water passes through / INSTALLATION 1. - Page 5 / F. INTEGRATED BYPASS INSTALLATION (MMB063) 1. Remove the lid 2. Remove the flow of the Magnesio by meter cable by unclipping both sides unclipping it from of the lid with a flat- underneath the head screwdriver, this connector assem- will allow access to bly.
-
Page 6: Water Pressure Test
/ G. WATER PRESSURE TEST • It is IMPORTANT that a pressure check is carried out. • Low and high pressure can result in either damage to, or failure of the unit. • If daytime static water pressure* exceeds 3.5 bar (50psi) a 5 bar (70psi) pressure limiter should be fitted. -
Page 7: Inlet & Outlet Connections
/ H. INLET & OUTLET CONNECTIONS DRAIN CONNECTION - See Fig 2 • Remove the main cover to access the inlet and outlet connections. • Remove grey retaining clips and also BSP connection points. Connect hoses to male BSP connection points, tighten to seal, then reinsert BSP connection points back into valve body. -
Page 8: Electrical Connection
/ L. ELECTRICAL CONNECTION With the power off, connect the transformer (supplied) to a continuous electrical supply. Push the flying lead from the transformer into the adaptor on the lead coming from the controller. / M. OBTAIN YOUR WATER HARDNESS •... -
Page 9: Set Water Hardness
/ P. SET WATER HARDNESS • Wait until display changes to Hardness. • Press Up Button to show Set Hardness with no flashing. • Use Up Button to set number as determined by your water hardness test. • Press to confirm setting. UP TO 30 DROPS ADVANCE ELECTRONIC DISPLAY TO 35 (REC MIN SETTING) 31 - 35 drops... -
Page 10: Blending Control
/ MAGNESIUM FLAKE FILL LEVEL FILL LEVEL / T. EXTRA REGENERATIONS • To start an automatic regeneration, press the left hand button and release, the display will count down from 15 to zero. If at any time you wish to cancel the count down, simply press again. - Page 11 / MONARCH WATER MAGNESIO WARRANTY - Effective January 2023 The Magnesio is fully covered by a 12 month parts and labour warranty for installation within mainland Great Britain from date of original purchase. Installations outside of these areas are automatically covered by a 12 months parts only ‘exchange’ warranty.
- Page 12 + 44 (0) 1986 784759 monarchwater.co.uk info@monarchwater.co.uk...
