PCB Piezotronics ICP M102B06 Installation And Operating Manual page 10

PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
ABLATIVE INSTALLATION
B
ABLATIVE COATING 3
MOUNTING HOLE PREPARATION:
M10x1 - 6H THRU

5
REFER TO SPEC SHEET. MODEL 065M29 ST STL SEAL AVAILABLE
4 BLACK VINYL ELECTRICIANS TAPE HAS BEEN FOUND TO BE AN EFFECTIVE ABLATIVE
MATERIAL, AS IS DC-4 SILICON GREASE
3 "CA" OPTION ONLY
A
2 MOUNTING TORQUE ON .437 [11.10] HEX: 5-8 FT-LBS [6.78-10.85 Nm]
1 ABOVE INSTALLATION SHOWN FOR WALL THICKNESS OF .34 [8.6].

WALLS .75 [19.0] TO CLEAR .437 [11.10] HEX AND ALLOW FOR SOCKET WRENCH
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.01
XXX ±.005
ANGLES  2 DEGREES
CABLE TOLERANCES IN ENGLISH
1"≤ LENGTH < 1' = +1"/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
5'≤ LENGTH < 100' = +6"/ - 0
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII
.003 - .005
2
ELECTRICAL CONNECTOR
10-32 UNF - 2A
MODEL 061A SERIES
ADAPTOR BODY
MATERIAL: 17-4 PH
2 .433 [11.00] HEX
5 MODEL 065A40
BRASS SEAL
MODEL 065A44
COPPER SEAL
[ ]
.020 .51
.015 .38
4
.437± .001 [11.13± .03]
DIMENSIONS IN MILLIMETERS
NJF
[ IN BRACKETS ]
DECIMALS X ± 0.3
XX ± 0.13
TITLE
ANGLES  2 DEGREES
CABLE TOLERANCES IN METRIC
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
30.5cm ≤ LENGTH < 1.5m = +5.1cm/ - 0
1.5m ≤ LENGTH < 30.5m = +15.2cm/ - 0
30.5m ≤ LENGTH = +30.5cm/ - 0
FILLETS AND RADII
0.07 - 0.13
2
REV
C UPDATED OVERALL LENGTH TOLERANCE, UPDATED NOTE 5
M10x1 - 6g

.030 [.76]
DRAWN CHECKED
10/06/22 10/06/22
JDM
INSTALLATION DRAWING
MODELS (M)101A & (M)102A
PRESSURE SENSOR
1
REVISIONS
DESCRIPTION
CLAMP NUT
1.47
.34 [8.6]
.31 [7.9]
.34 [8.6] 1

THICKER
ENGINEER
10/06/22
AJA
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE: 2.5X
1
DIN
53183
B
[ ]
 
.05 37.4 1.3
A
6449
SHEET 1 OF 1
