  • Page 1 MTMK5883 Operation Manual V2.0...
  • Page 2 Micro Sensor CO., LTD. reserves the right to modify this manual due to product technology and process updates. If there is any change, no further notice will be given. Please pay attention to the latest version of this manual. The company reserves the right of final interpretation of this manual.
  • Page 3: Specifications

    To use the products better, please take some time to read this operation manual very carefully before using them. 1 Introduction The MTMK5883 temperature transmitting controller is a fully digital measurement and control product that integrates temperature measurement, display, contact control, and transmitting output. It can be directly installed at the on-site temperature measurement point or on the control screen of the test bench.
  • Page 4: Outline Structure

    Long-term Stability: ± 0.1%FS/year Environment Temperature: -30℃~70℃ Medium Temperature: -200℃~500℃ Storage Temperature: -40℃~120℃ Probe Material: Stainless steel 304/316L/other Housing Material: Cast aluminum housing IP65 3 Outline Structure (105) (155) Grounding Stud 2×M6 34±0.1 SW27 (Default) Installation Thread Probe Diameter Fig. 1 Installation...
  • Page 5 4.1 Checking Before Installation a) The measuring range in site should be suitable with the measuring range of the transmitting controller; b) Please check if the installation and thread are suitable with the condition in site. 4.2 Electrical Connection The electrical definition of the wiring terminal is shown in Figure 2 and Table 1, and the wiring method is shown in Figure 3.
  • Page 6 Check whether the package box is in good condition and set it down according to the “Upward” sign; b) Do not unpack it by force to avoid damaging products or accessories. 5.2 Complete Set Shipment includes: MTMK5883 Temperature Transmitting Controller 1pc Operation Manual Quality Certificate 5.3 Storage...
  • Page 7: Function Setting

    The transmitter should be stored in the ambient temperature of -20℃~70℃, the relative humidity is not more than 80% of the dry and ventilated room, indoor air does not contain corrosive substances to the transmitter. 6 Function Setting The setting of instrument includes 3 buttons, as followed: Button Name Function...
  • Page 8: Manual Setting

    7 Manual Setting Switch point setting process: Measurement Status Correct Password 0001 Display Filter AL1 Pull-in Value Incorrect Password AL1 Release ValueL AL2 Pull-in Value AL2 Release ValueL FILT This value is the display filter coefficient. AL1H: This value is the pull-in value of switch 1 (AL1/SP1). AL1F: This value is the release value of switch 1 (AL1/SP1).
  • Page 9 8 Installation Guide MTMK5883 can be directly installed on the pipeline through a threaded interface. In critical applications (such as severe vibration or impact), the bellows can be used for mechanical decoupling.
