Power Soak PS-201 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
888-994-7636, fax 888-864-7636
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE.
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED
IN THIS MANUAL.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Power Soak
suggests that if you are suspicious of damage to make a notation on the
with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
Information contained in this document is known to be current and accurate at the time of printing/creation. Reference our product line website for the most updated product information and
speci cations. © 2023 Electrolux Professional, Inc. All Rights Reserved.
This manual provides information for:
PS-201
READ,
PART NUMBER 37099, REV. A (08/23)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS-201 and is the answer not in the manual?

Questions and answers

Related Manuals for Power Soak PS-201

Summary of Contents for Power Soak PS-201

  • Page 1 NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the consignee to inspect the container upon receipt of same and to determine the possibility of any damage, including concealed damage. Power Soak suggests that if you are suspicious of damage to make a notation on the with the carrier.

  • Page 2: Product Introduction

    Every system is manufactured to last, with only high-quality, heavy-duty, 14 gauge stainless steel used in its construction. All electrical components used in a Power Soak system are of the highest quality. The faucets and drains are designed for quick filling and emptying of the system's sinks.

  • Page 3: Chemical Hazard

    Power Soak Systems is not a chemical manufacturer, importer or distributor. Power Soak Systems, Inc. can assist your chemical representative but will not make specific brand recommendations.

  • Page 4: Factory Assistance

    Detergents Improper detergents will damage equipment! Use of the correct detergent in your Power Soak system is critical to its washing performance. If you are having problems with cleaning results, please contact the factory. Power Soak machines require a low-foaming, metal/aluminum-safe detergent that is safe for the hands.

  • Page 5: Preparing The System

    Preparing the System Filling the System At the beginning of each day or shift, fill the sinks with water that is metered to approximately the correct operating temperatures: • Wash sink (115°F / 48°C) • Rinse sink (75°F / 24°C) •...
  • Page 6 Adding Detergents & Sanitizers Manual Chemical Dispensing After the sinks have been filled with water, add the proper amount of detergent and sanitizer. The detergent goes into the wash sink (the sink with the water jets) and the sanitizer goes into the sanitizer sink (the last sink).

  • Page 7: Controls And Features

    Dirty pots and pans should be brought to the Power Soak in a timely manner. Do not allow items to sit and air dry. The quicker that items are brought to the Power Soak and put in the wash tank, the easier they are to clean!
  • Page 8 Some pots and pans stack for storage. This is referred to as “nesting” when it occurs during a Power Soak wash cycle. Make sure that nested items are separated and loaded one at a time. Nested items in the wash sink will not be properly washed.
  • Page 9 Loading and Washing Utensils Each Power Soak system comes with a utensil basket that hangs in the wash sink. All utensils and other small wares should be loaded into and washed inside this basket. Do not place knives or other sharp objects in the Power Soak.
  • Page 10 Power Soak machine overnight. Load the items to be deep cleaned into the Power Soak's wash sink, turn the machine on and leave it running overnight. Items that have been cleaned overnight can be removed, rinsed, sanitized (if necessary) and put away or back in place.
  • Page 11 Wash, Rinse and Sanitizer Clean-Up Between each water change and at the end of each night, all tanks and drain boards should be thoroughly cleaned with hot, soapy water. It is also recommended to wipe down all the tanks and drain boards with a sanitizing agent.
  • Page 12 This completes the list of maintenance procedures that will need to be performed on the Power Soak machine. It is not necessary to grease the motor bearings, as they are permanently sealed. If you there any questions regarding the preventive maintenance procedures, please contact the...
  • Page 13 Slow Flashing – “POWER ON” – system is energized and ready to fill. Solid Illumination – “READY” – wash sink is full; system is ready. Blue Light The blue light is not used with the PS-201 control system Red Light The red light is not used with the PS-201 control system.
  • Page 14 After reviewing the status of the control panel LED’s, there is still an operating problem, refer to the following troubleshooting guidelines: • Check the main electrical power breaker for the Power Soak system to see that it is in the “ON” position.
  • Page 15 Explanation of LED Sequence The control enclosure of the Power Soak machine will need to be opened to verify the proper operation of the operating logic. This will require examination of the LED’s on the programming module. The Universal Programming Module (UPM) is mounted to the inside of the control enclosure cover.
  • Page 16 • Be sure that all connections to and from the liquid level sensors are secure and that there is no physical damage to the wiring. • If damage to connectors and/or wiring is found, contact Power Soak Systems, Inc. at 800-444-9624.
  • Page 17 Prior to calling, please note the “Error Code” (if any) that can be identified by observing LED #2 on the UPM. If there is a control logic error, LED #2 will flash with a “blinking” pattern. The definitions for the patterns are as follows: “...

  • Page 18: Electrical Requirements

    Please refer to the detailed installation instructions that were sent with the Power Soak machine. Electrical Requirements The electrical requirements of the Power Soak machine are shown on the serial number plate located on the front of the wash sink, adjacent to the control panel enclosure and inside the enclosure itself.

  • Page 19: Plumbing Requirements

    Specific part numbers and part information can be obtained from the factory by calling 800-444-9624. Plumbing Requirements The PS-201 unit requires the following plumbing connections: • 3/4” (19mm) or 1/2” (12 mm) hot and cold water supply lines. • One waste water connection (minimum 1 1/2” / 38mm).
